Figure 4: Get access to the Eval Kit through these ports

2.3 Put one plug of the HDMI cable into an HD monitor and put the other plug into the HDMI port of the
Eval Kit (see Figure 4). Alternatively you can connect the Eval Kit to a DSI display.
2.4 Put one plug of the USB Debug cable into one USB port of the computer and put the other plug into the
Debug USB Micro B port of the Eval Kit (see Figure 5).
Explanation:
1. USB Recovery
Explanation:
1. HDMI port
24
/First steps
