List of illustrations

Figure 1: Top view of the Eval Carrier
Figure 2: Function block diagram for the Evaluation Kit
Figure 3: Packaged Eval Kit and its components
Figure 4: Get access to the Eval Kit through these ports
Figure 5: Get access to the Eval Kit through these ports
Figure 6: Turn on the Eval Kit with these components
Explanation of the symbols

Indicates a list of various items

Indicates the result of a step
Indicates additional information

Indicates hyperlinked chapters and sections within the user guide
Abridged list of abbreviations
SOM
System on a Module, here: Meerkat K1 Processor Module
Eval Kit Meerkat K1 Evaluation Kit
ECB Meerkat K1 Evaluation Carrier Board
TBD To be defined
