MDI / MDI-X automatic crossover detection
Ethernet V2 / IEEE 802.3
2 status and activity LEDs
RJ45 LAN

2.3.2 ANT Connector

2.3.3 Power Connector

2.4 Technical Specifications

Hardware Architecture
PROCESSORS
MEMORY
STORAGE UNIT
LAN Interface
PROTOCOLS
SPEED
12
RJ45 PIN
1
2
3
4
5
6
7
8
PIN
Internal
External
PIN
Internal
External
Coldfire MCF5328
32 Mbytes in RAM.
FLASH Memory (8 Mbytes).
Ethernet (802.3).
10/100 Mbps (10/100BaseT)
LAN
Tx+(input)/POE+
Tx-(input)/POE+
Rx+(output)/POE-
POE+
POE+
Rx-(output)/POE-
POE-
POE-
ANT
RF in/out
GND
ANT
POSITIVE
NEGATIVE
