SixThreeZero AROUND THE BLOCK Assembly Manual page 50

1 3
P H I L L I P S
S C R E W D R I V E R
Reference the image below on the left, if the chain is cen-
tered in between the inner and outer cage plates, you
can move on to step 14, Micro Adjustments. If the chain
is NOT centered in between the inner cage, you will need
to use a Phillips head to center the inner walls of the cage
to the chain. Looking overhead at the cage and inspect
its current position.
H AV I N G T R O U B L E ? WA N T L I V E H E L P ? C A L L 3 1 0 . 9 8 2 . 2 8 7 7 O R E M A I L T E A M @ S I X T H R E E Z E R O . C O M .
1 4
P H I L L I P S
S C R E W D R I V E R
Based on the screws original position, take note of the
amount of quarter turn rotations given in either direction
to the L screw, until the inner and outer cage plates are
centered. If the outer cage plate is too far in and rubbing
against the chain, you have to turn the L screw counter-
clockwise. If the inner cage plate is too far out and rubbing
against the chain, you have to turn the L screw clockwise.
