SixThreeZero AROUND THE BLOCK Assembly Manual page 30

1 0
Pull the cable outward, reducing the distance between
the brake pads and the rim by about 1/4 inch on both
sides. Retighten the adjustment screw.
H AV I N G T R O U B L E ? WA N T L I V E H E L P ? C A L L 3 1 0 . 9 8 2 . 2 8 7 7 O R E M A I L T E A M @ S I X T H R E E Z E R O . C O M .
C A B L E
1 1
5 M M
A L L E N K E Y
Make sure the pads are evenly lined up with the rim. If
the pads rub against the tire, they are too high; if they
don't make full contact with the rim when braking, they
are too low.
Adjust the positions by holding the brake pad with one
hand and loosening the nut on the back with a 5mm
Allen key.
A D J U S T W I T H
5 M M A L L E N K E Y
