SixThreeZero AROUND THE BLOCK Assembly Manual page 27

0 2
Attach the brake cable to the brake lever
by squeezing the lever and inserting the
barrel into the barrel hanger.
0 4
Slide the cable housing up toward the
brake lever until it fits snug inside the barrel
adjuster.
B A R R E L A D J U S T E R
WATC H A S S E M B LY V I D E O S O N O U R Y O U T U B E C H A N N E L , H T T P S : / / S I X T H R E E Z E R O . C O M / PA G E S / A S S E M B LY
B A R R E L B A R R E L
A D J U S T E R H A N G E R
0 3
Pull on the cable and slide it through the
narrow crevice that runs along the brake
lever.
0 5
Turn the lock ring on the barrel adjuster
clockwise, tightening the barrel to prevent
any loose movement.
B R A K E
L E V E R C R E V I C E
LO C K R I N G
