SixThreeZero AROUND THE BLOCK Assembly Manual page 17

0 5
6 M M
A L L E N K E Y
Line up the stem, frame, and front wheel, then tighten.
the handlebar stem bolt.
Loosen handlebar adjustment bolt using the 6mm Allen
key. Change the angle of the handlebars to your liking.
T I G H T E N
B O LT
WATC H A S S E M B LY V I D E O S O N O U R Y O U T U B E C H A N N E L , H T T P S : / / S I X T H R E E Z E R O . C O M / PA G E S / A S S E M B LY
A D J U S T B O LT
0 6
P H I L L I P S
S C R E W D R I V E R
The front reflector will be installed into the hole at the
top of the fork and below the head tube. Tighten with
the Phillips head screw driver and 10mm wrench.
N O T E
Order from front to back:
LONG BOLT, WASHER, FORK, WASHER, NUT.
F R O N T
R E F L E C TO R
