SixThreeZero AROUND THE BLOCK Assembly Manual page 31

1, 3, 7, & 21 speed

Advertisement

1 2
If one pad seems to run against the rim while the other
still has plenty of space, you will need to center the
brakes. To do this, adjust the spring tensioner screws
located at the base of each brake arm.
Tightening the screw on the right brake arm pushes the
right brake pad away from the rim, and the left brake pad
towards the rim.
Loosening the right screw allows the right brake pad to
move closer to the rim, and the left brake pad away from
S P R I N G
T E N S I O N E R S C R E W
the rim.
WATC H A S S E M B LY V I D E O S O N O U R Y O U T U B E C H A N N E L , H T T P S : / / S I X T H R E E Z E R O . C O M / PA G E S / A S S E M B LY
