Page 2
Thanks for buying our Fitness equipment, Do some warm-up exercise before use, you’ll get twice the result with half the effort. Such as follows: extend the neck up and down twist the waist left and right level push forwards upright straighten one's back - 2 -...
left and right poise exercise up and down extend exercise thigh extend exercise calf extend exercise SAFETY GUIDELINES: Before beginning any exercise program, you should consult with your doctor. It is recommended that you undergo a complete physical examination. Please follow the instructions: 1.
Page 4
5. Make sure all parts are assembled, nuts and bolts are tightened 6. Do not use the treadmill if the unit is disassembled in any way 7. When connecting the power cord, plug the power cord into a grounded circuit. No other appliance should be on the same circuit.
PART LIST PART NO PART NAME Q'TY Motor cover Front roller with fly wheel Running belt Rear roller Running deck Motor belt Motor Speed sensor frame Speed sensor Motor frame Side rail Running platform tube plug Control board Power wire Power wire cushion Fuse group Power key...
Page 7
Pulse key of handlebar Handlebar foam Handlebar tube plug Safety key Computer ST4.8*16 Screw M8*50mm Allen head bolt Ø8 Washer M8*65mm Allen head bolt M6*40 bolt Ø6 Washer M6 Nylon nut M6*50 bolt M4*10 bolt Ø4 Washer ST2.9*8 Screw M8*85mm Allen head bolt M8 Nylon nut M8*16mm Allen head bolt M8*35mm Allen head bolt...
Page 8
HARDWARE COMPARISON CHART For your convenience, we have identified the hardware used in the assembly of this product. The chart below is provided to help you to identify items that may be unfamiliar to you. Ø e l l M8*20mm Allen head bolt e l l Ø...
ASSEMBLING INSTRUCTIONS WARNING: Please put on all the screws, washers and bolts then tighten them. STEP1: Fix uprights onto base frame with Ø8 Washer (42), M8*40mm Allen head bolt(60), Ø10 Washer(64) and M10*20mm Allen head bolt(63) ATTENTION: Be careful when you connect the two console-controller wires. There are pins inside connector, the pins must be straight, and otherwise it will cause problems.
Page 10
STEP3: Fix computer handlebar frame onto uprights with M10*50mm Allen head bolt (66) and Ø8 Arc washer (67) STEP4: Fix handlebar cover onto computer handlebar frame as left photo show - 10 -...
Page 11
STEP5: Fix computer onto computer handlebar frame with Ø4 Washer (49) and M8*40mm Allen head bolt (68) STEP6: Folding illustration: o unfold the treadmill: Folding illustration: To drop down treadmill: Strike the damper. (as shown by the arrow on left side).
To fold up treadmill: Both hands hold on the bottom end covers (arrows show in the left and right side) and lift up the treadmill. COMPUTER OPERATION Panel layout - 12 -...
Page 13
The Operation Power The required main power is 220 - 240 VAC KEY ILLUSTRATION START/STOP: START: to start the treadmill. STOP: to stop/pause treadmill(press stop key for long 2seconds to stop treadmill, press stop key within 2 seconds to pause treadmill) MODE: In the waiting mode, press MODE key to change the NORNAL MODE TIME MODE DISTANCE MODE CALORIESMODE P1 P2 P3 P4 P5 P6 NORNAL MODE...
Page 14
· Press MODE key to change NORNAL MODE TIME MODE DISTANCE MODE CALORIESMODE P1 P2 P3 P4 P5 P6 NORNAL MODE in turn. The selected mode will flash. TIME MODE · The default time is 30 minutes. · Press SPEED+/SPEED- key to adjust the target value.(10:00-99:00) ·...
Page 15
· Press STOP key for 2 seconds to stop the treadmill but press it in two seconds to pause the treadmill. · When change the level, there will be BBBBB warning sounds. · Change the level according to the setting of time. BODY FAT MODE WAITING MODE ·...
Page 16
Speed ◆ Error Message Error Condition Illustration Check Further Action Displays Connection error Check that the cables between Replace the connecting between display panel and controller are well cables. panel and motor connected or not Replace the device. controller. Replace the panel. Replace the adapter.
walking belt 2. Check that the speed sensor 2. Replace the device. cable is well connected or not. 2. Check the placement of sensor or the photo disk is correct or not. Displays Er5 Over current Check the loading. Replace the device. IGBT Displays Er6 Over...
Page 18
the directions below: 1. Walking belt has shifted to the left: First unplug the power cord from the surge protector. Using the hex key provided, turn the left rear roller adjustment bolt 1/4 turn in the clockwise direction. Plug the power cord back into the surge protector and run the treadmill at 2.5 mph.
DECK LUBRICATION: The walking belt has been pre-lubricated at the factory. However, it is recommended that the walking board be checked periodically for lubrication to ensure optimal treadmill performance. Every 3 months of operation lift the sides of the walking belt and feel the top surface of the walking board as far as you can reach.
