Evaluation Board User Guide

QUICK START GUIDE

Follow these steps to quickly evaluate the
1. Install the ADF435x software from the CD.
2. Connect the EVAL-ADF4351EB1Z
the necessary drivers.
3. Follow the hardware driver installation procedure.
4. Ensure that Switches SW1 and SW2 are closed.
5. Run the ADF435x software.
ADF4351 device:
to the PC and install
Rev. 0 | Page 3 of 20
6. Select the USB board connection and the
in the Select Device and Connection tab of the software
front panel window.
7. Click the Main Controls tab. Update all registers.
8. Connect the spectrum analyzer to J2.
9. Measure the results.
UG-435
ADF4351 device
