- Page 1 7” S-Series HMI W07IB3S-PCM1AC W07IB3S-PCM1 Quick Start Guide V1.1 Document Part Number: 9152070I1002 Please read these instructions carefully before using this product, and save this manual for future use.
- Page 2 Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. We assume no responsibility or liability for the...
-
Page 3: Table Of Contents
Contents Getting Started Unpacking Accessories Description Of Parts Mounting VESA Mount Flush/ Panel Mount Connector Description DC Input Connector Serial Port Connector LAN (RJ45) Connector USB A Type Connector HDMI Connector Turning ON or OFF Turning ON Turning OFF Operating the HMI Device Hot Tab Menu Utilities Brightness... - Page 4 Software Developer Support Winmate Software Development Kit Winmate Download Center Winmate File Share Technical Specifications HMI Device Specifications HF RFID Reader Specifications...
-
Page 5: Getting Started
Getting Started Congratulations on purchasing Winmate® 7” S-Series HMI. Interactive and smart automation systems of intelligent buildings are in a fast growing phase. Winmate® multi-touch S-Series HMI is suitable for home automation and room management systems. Flat surface is easy-to-clean and delivers aesthetically pleasing look for any interior. -
Page 6: Unpacking
Unpacking Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Accessories Standard factory shipment list: Quick Start Guide Driver CD &... -
Page 7: Description Of Parts
1 x USB 3.0, 1 x USB 2.0 ④ HDMI ⑧ *RGB LED Light Bar *Note: RGB LED light bar only available for the model number W07IB3S-PCM1AC Please read these instructions carefully before using this product, and save this guide for future use. - Page 8 Dimensions:...
-
Page 9: Mounting
Mounting 7” S-series HMI devices come with different mounting options suitable for most of the industrial and commercial applications. VESA Mount Dimensions Screw hole diameter Compatibility 75 x 75 mm VESA M4x5 mm Swing arm mounting kits Flush/ Panel Mount Wall cutout Screw hole diameter 131.4 x 175.4 mm... -
Page 10: Connector Description
Connector Description DC Input Connector DC power source input is a 12V DC-in jack connector. Pin № Pin № Name Name DC_IN Serial Port Connector Use COM1 serial port connector to connect your HMI to external devices such as mouse, modem or printer. Pin №... -
Page 11: Usb A Type Connector
USB A Type Connector Use USB A Type (USB2.0) connector to connect your HMI device to other USB2.0 compatible devices. Use USB 3.0 connector to connect your HMI device to other USB3.0 compatible devices. Pin № Pin № Name Name USB_D- USB_D+ STDA_SSRX-... -
Page 12: Turning On Or Off
Turning ON or OFF Turning ON Follow the following steps to turn on your device: 1. Connect the AC adapter to the DC-in jack connector on the back side of the HMI device. 2. Connect the power cord to AC adapter. 3. -
Page 13: Turning Off
Turning OFF You can Turn OFF the HMI device with the Windows power settings. To shut down the device: 1. Tap Start >Shut down. 2. Wait for your HMI device to completely turn off before disconnecting the power cord (if necessary). Please read these instructions carefully before using this product, and save this guide for future use. -
Page 14: Operating The Hmi Device
Operating the HMI Device Winmate® 7” S-Series HMI comes with HoT Tab, which allows you to operate the HMI device. Hot Tab Menu To open the Hot Tab menu: 1. Double-click the Hot Tab icon on the Windows desktop. 2. The Hot Tab main menu will appear on the screen as shown below. -
Page 15: Brightness
Brightness Tap Brightness button to show current brightness level. To reduce the brightness, drag by touch this icon to the left. To enhance the brightness, drag by touch this icon to the right. Tap Close icon to save the changes and exit the interface. Volume Tap Volume button to show current brightness level. -
Page 16: Testing Led Light Bar
Testing LED Light Bar Tap Light Bar to access the LED light bar control panel, and select Red / Green / Blue/ Orange color to be displayed on the LED Bar. Performance User can adjust the performance level of the HMI device. There are four options available: ... -
Page 17: Using Front Camera
Using Front Camera Your device might have built-in camera based on your order. Camera Interface Perform one of the following to open the camera: 1. Press the F1 key. 2. Tap then double-tap to display the HotTab screen. Select Camera. No Item Description Tap to record videos... -
Page 18: Shooting Photos
Shooting Photos 1. Open the Camera 2. Focus on the object 3. Tap to capture the object 4. By default, the photo preview is displayed briefly on the screen The preview screen automatically closes after 3 seconds. Alternatively, do one of the following: - Tap to delete the photo and return to the camera screen... -
Page 19: Camera Settings
4. Tap to stop recording and return to the camera screen 5. To playback the video, browse for the video file and play using a media player application on your device Camera Settings 1. Tap to open the setting page 2. -
Page 20: Using Hf Rfid Reader
Using HF RFID Reader Notice that HF RFID Reader is an optional feature for 7” S-Series HMI and may not be present in your device. HF RFID is commonly used for ticketing, payment, and data transfer applications. The RFID Reader is located on the bottom right front side of the HMI device. The COM Port setting in RFID Reader is “COM 14”. -
Page 21: Reading Mode
Reader Demo Version 1.04 Reading Mode Select the default RFID Reader COM14or press Search on the upper left corner of the screen. The system will automatically find RFID COM port, show the Version. Item № Key button Function Displays the current version of RFID Reader E1- Version system E2- Reset... -
Page 22: Writing Mode
UID0 Menu The system will read the data once the card will be near. You can select different reader modes. Each mode is described below. Item Key button Function № A0- Continuous The RFID Reader will perform a series of multiple Read (default) scanning operations A1- Once Read The RFID Reader will perform a single scanning... -
Page 23: Software Developer Support
Software Developer Support Winmate Software Development Kit Winmate® provides Software Development Kit (SDK). The table below lists SDK provided by Winmate for 7” S-Series HMI with Intel® Celeron® N2930 processor: Item File Type Description Watchdog SDK Digital I/O SDK Utility... -
Page 24: Technical Specifications
Technical Specifications HMI Device Specifications Model Name W07IB3S-PCM1AC / W07IB3S-PCM1 7” TFT (Widescreen) Size Resolution 1024 x 600 Brightness 500 (typ.) Display Specification Contrast Ratio 700 : 1 (typ.) Viewing Angle -75~75 (H);-70~75(V) Max Colors 262K (6bit) Touch PCAP Multi-Touch support 5 points Intel ®... -
Page 26: Hf Rfid Reader Specifications
Power Input 12V DC-in Jack Power Power Management Consumption Dimensions 189.4 x 145.4 x 37.7 mm (W x L x H) Mechanical Mounting VESA Mount (75 x 75 mm) Specifications Cooling System Fanless design Operating Temp. 0°C ~ +55°C Humidity 10% ~ 90% (non-condensing, RH) Environmental Considerations... - Page 27 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, Taipei 241, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
