GoBook MR-1
Down
6 Display/Monitor Switch
7 C1 & C2
8 Window Focus
9 Keyboard Backlight
on/off

Radio ON/OFF Hot Key (option)

CAUTION FAA regulations require that all transmit/receive devices be turned off during flight. If you have radios
(including GPS) in your computer, the Radio ON/OFF Hot Key, is used to turn your radios off during flight. If you
have radios and you do not have a switch to turn the radios off, either leave your computer off during flight or
contact your help desk for assistance.
The wireless Radio ON/OFF Hot Key
to all radio devices (including GPS, Bluetooth, WLAN, and WWAN radios).
To Turn all Radios on or off
1. Press Fn+ to power off all radio devices (airplane mode).
2. Press Fn+ again to turn radio power on.

Application Launch Buttons

Pressing either of them, once they are programmed starts the application of your choice. The application launch
buttons are marked C1 and C2 on the keyboard.
To program the Application Launch Buttons
1. Select Start, All Programs, Mobile Computer Tools, Configure On-Screen Display, C1, and C2 Settings
2. Select the C1 or C2 tab on the GD-Itronix OSD Configuration screen.
3. Use the drop-down menu to select an application to associate with the Launch Button
file://C:\Documents and Settings\harwoodm\Local Settings\Temp\~hh96AE.htm
Switches between the GoBook MR-1 LCD display
and an external monitor. (An external monitor may
be added using the
Automatically opens a pre-defined application. (see
C1
Application Launch
C2
Moves foreground window back and places focus on
next active window
Turns the keyboard backlight off and on
(the blue function icon above the R key) toggles the power on and off
Office Dock
Buttons)
