GoBook MR-1
Maintain the environmental seal of the computer by keeping all external access doors closed and latched
Avoid exposing the unit to extreme temperatures or moisture when the doors are open
Periodically backup
Hard Drive Installation and Removal
The GoBook MR-1's internal hard drive is accessible from the back of the unit.
To remove the hard drive:
1. Save and backup any work, and shut down the
computer
2. Hold the computer in both hands and turn over so
you are looking at the bottom with the battery latch
at the back of the unit in your right hand.
3. Place your thumbs on the battery latches on the
either edge of the battery and press in.
3. Lift the battery away from the unit.
1. Hold the GoBook MR-1 as shown and press in
with the finger of your right hand on the latch
next to the hard drive (see circle in illustration)
until you hear it click.
2. Use the thumb on your left hand to slide out the
hard drive.
3. Once the drive is projecting from the GoBook
MR-1, grasp it gently and pull it straight out of
the unit.
To insert a hard drive:
1. Place the hard drive in the slot on the GoBook
MR-1 and slide it in straight and slow.
NOTE Make sure you keep the drive straight and
press gently so as not to damage the exposed hard
drive connector pins.
2. Slowly slide in the drive until the latch clicks
into place.
file://C:\Documents and Settings\harwoodm\Local Settings\Temp\~hh96AE.htm
or archive important files and data.
