GoBook MR-1
Press to decrease display brightness
Automatic Dim Feature
To save battery power, your computer automatically dims the display when the computer is not attached to external
power.
NOTE You may still manually adjust display brightness.
See Managing Power for more information on power management features.
To Enable or Disable Automatic Dim
1. Restart the computer by selecting Start, Turn Off Computer, Restart.
2. Press Enter during boot up to open the Setup Utility.
3. Select Launch System Setup Menu.
4. Use the right arrow key to select the Advanced screen.
5. Use the down arrow to select Auto Brightness Control and press Enter.
6. Use the down arrow to select Auto DIMMING and press Enter.
7. Choose Enabled or Disabled and press Enter.
8. Press Esc to save this setting and exit BIOS Setup.

Adjusting Display Resolution

To Adjust Display Resolution
1. Right click on the desktop.
2. Select Properties and then select the Settings tab. The dialog box indicates the monitor screen resolution.
3. Use the Screen Resolution slide bar to adjust the resolution. Normally, you should use the resolution
suggested for the display or monitor.
NOTE Using a lower resolution than the screen was designed for will reduce the area of the display. Higher
resolution modes may be used, as long as the monitor supports them.

Simultaneous or Extended Display

The computer's display and multimedia capabilities are great for viewing movies or giving presentations. However,
because of the small size of the GoBook MR-1 display you may prefer to connect an external monitor. The optional
Office Dock or Expansion Unit, allows this computer to support simultaneous LCD and external display output via
the external monitor port located on the Office Dock. You can also connect other output display devices such as
LCD projection panels for large-audience presentations. See
more information.
file://C:\Documents and Settings\harwoodm\Local Settings\Temp\~hh96AE.htm
Attaching an External Monitor or Video Device
