GoBook MR-1
NOTE When external power is properly applied, the External Power LED
CAUTION This notebook computer is designed to be used with the provided dedicated AC Adapter or Vehicle
Adapter only
To Attach AC Power:
1. If the computer has a dust cover over the back edge
connections, pull it back and rotate it to the side.
2. Connect the AC adapter power cord to the AC
adapter.
2. Connect the AC adapter to the DC power port on
the back of your computer.
NOTE Push the DC jack firmly into the
computer until it "clicks."
2. Connect the AC adapter power cord to a properly
grounded AC outlet.
NOTE It is recommended you use a quality
protector.
Using the (optional) Office Dock
1. Insert the Office Dock into the back of the
computer.
2. Insert the power suppy cord into the DC-in jack on
the right side of the dock.
3. The power LED illuminates to indicate that current
is reaching the computer. When you connect the
Office Dock it automatically begins charging the
computer's battery. At ambient temperature, (room
temperature of about 70ºF), the battery should
charge from empty to 90% in less than three hours
if the unit is suspended or off. It should take less
than four hours if the unit is in use.
Using the (optional) Vehicle Adapter
1. Insert the vehicle adapter's power cord into the
DC-in jack on the left side of the computer.
2. Insert the 12V (cigarette lighter) adapter into the vehicle's 12V socket, turning it slightly to make a good
connection.
file://C:\Documents and Settings\harwoodm\Local Settings\Temp\~hh96AE.htm
surge
Page 31 of 90
lights.
