3.1 Overview

Electret microphone
Severable from the preamplifier
(inside the windscreen).
Preamplifier
Graphical backlighted LCD-
screen : 240 x 160 pixels.
It displays both reserved areas
for the setting
measurement and areas for
results presentation.
Monochrome, with 16 grey/blue
levels, it participates to the
intuitive manipulation of the
sound level meter .
The back of the instrument contains a battery compartment door, a threaded hole for mounting on a tripod, a location for the nameplate
and a location for the calibration label.

Presentation of the sound level meter

of the
Bottom part : protected by a flexible and removable
rubber breastplate, it contains all input/output and
external power plugs.
Windscreen : essential to
reduce the noise induced by air
currents.
Keyboard : it consists of only 8
sensitive keys. Its ergonomy allows
an immediate and easy use of the
sound level meter.
