MP 110 – MP111 – MP112 – MP 115
DESCRIPTION OF THE DEVICE
Backlight key
Select key
PERFORM A MEASUREMENT
Turn on the device by pressing on « On/Off/Esc ».
➢
The device displays its name « MP110 », « MP111 », « MP112 » or « MP115 », then performs an autozero.
Connect the pressure tubes.
➢
The device displays the pressure.
PERFORM AN AUTOZERO
The device is on and displays the pressure measurements.
Press on « OK ».
➢
« Autozero » displays on screen, the device performs an autozero then returns to the measurements display.
DigiParts GmbH
Manometer
www.digiparts.ch
OK key
On/Off/Esc key
Hold/min/max key
info@digiparts.ch
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kimo MP Series
Summary of Contents for Kimo MP Series
- Page 1 Manometer MP 110 – MP111 – MP112 – MP 115 DESCRIPTION OF THE DEVICE OK key Backlight key On/Off/Esc key Select key Hold/min/max key PERFORM A MEASUREMENT Turn on the device by pressing on « On/Off/Esc ». ➢ The device displays its name « MP110 », « MP111 », « MP112 » or « MP115 », then performs an autozero. Connect the pressure tubes.
- Page 2 FREEZE THE MEASUREMENT During a measurement : Press on « Hold/min/max ». ➢ « Hold » appears on the screen and the measurements are frozen. Press on « On/Off/Esc » to exit the hold function. ➢ The device returns to the measurement display. DISPLAY THE MAXIMUM AND THE MINIMUM Once the measurement are frozen : Press once on «...
- Page 3 Adjust the auto shut-off : The device is on and display the measurement. Press on « Select » until « AUTO OFF » blinks on screen. ➢ Press on « OK ». ➢ The time before device auto shut-off blinks at the bottom of the screen. Press on « Select »...
