Forcepoint Next Generation Firewall 4U Hardware Guide
Model 6205 features
The figures and tables show the appliance components.
6205 front panel
1 Interface module slots
The upper slots are numbered 1—4 from left to right.
The lower slots are numbered 5—8 from left to right.
2 2 USB 2.0 ports
3 Console port (speed 115,200 bps)
4 VGA port
5 40 gigabit QSFP+ port
The port number is eth0_2.
6
Fixed Ethernet ports
The upper port number is eth0_0.
The lower port number is eth0_1.
7 2 USB 3.0 ports
8 IPMI port (do not use)
9 (From left to right) power button, indicator lights, UID button
1
2 3 4
5
6
7 8
9
3
