Forcepoint Next Generation Firewall 4U Hardware Guide
Install a 6205 appliance in a four-post rack
Attach the appliance to the front posts of the rack, and optionally use the long rack-mounting brackets to attach
the appliance to the back posts of the rack.
Steps
1) (Optional) Attach a long bracket to the back posts of the rack, then attach the appliance to the bracket.
a) Attach a long bracket to each of the back posts of the rack.
b) Attach four screws to each side of the appliance.
c) Lift the appliance into the rack, and guide the screws in the side of the appliance into the two grooves of
the bracket.
The bracket is used to support the appliance when setting the depth of the appliance in the rack.
