Forcepoint 110 Hardware Manual

Revision a
Hide thumbs Also See for 110:

Advertisement

Quick Links

Download this manual
Next Generation
Firewall
Hardware Guide
Models 110, 115
Revision A

Advertisement

loading
Need help?

Need help?

Do you have a question about the 110 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Forcepoint 110

Summary of Contents for Forcepoint 110

  • Page 1 Next Generation Firewall Hardware Guide Models 110, 115 Revision A...
  • Page 2 On the Forcepoint support website, you can find information about a released product, including product documentation, technical articles, and more. You can get additional information and support for your product on the Forcepoint support website at https://support.forcepoint.com. There, you can access product documentation, Knowledge Base articles,...
  • Page 3 Forcepoint Next Generation Firewall Hardware Guide | Models 110, 115 Model N110 features The figures and tables show the N110 (110) appliance components. Front panel The front panel has indicator lights. Power indicator Status indicator Management (MGMT) indicator Internet connectivity indicator Back panel The back panel includes the power connector and ports.
  • Page 4 Forcepoint Next Generation Firewall Hardware Guide | Models 110, 115 Note: This appliance does not support hardware flow control on the console port. If you do not disable this feature when using a terminal emulator program, you cannot enter commands into the console;...
  • Page 5 Forcepoint Next Generation Firewall Hardware Guide | Models 110, 115 Number Indicator Status Description Green 1 Gbps link. Model N115 features The figures and tables show the N115 (115) appliance components. Front panel The front panel has indicator lights. Power indicator...

  • Page 6: Back Panel

    Forcepoint Next Generation Firewall Hardware Guide | Models 110, 115 Back panel The back panel includes the power connector and ports. Interface module slot Power connector USB ports Console port (speed 115,200 bps) Fixed Ethernet ports 0–1 (from left to right) Ports 0–7 in the integrated switch (from left to right, 0–3 on the top row and 4–7 on the bottom row)
  • Page 7 10 Mbps link. Amber 100 Mbps link. Green 1 Gbps link. Supported interface modules Model 115 Forcepoint NGFW appliances support copper and small form-factor pluggable (SFP) modules. Note: Do not remove any stickers from modules — they contain important information.
  • Page 8 Forcepoint Next Generation Firewall Hardware Guide | Models 110, 115 For a list of all available interface modules and compatibility information, see Knowledge Base article 10245. MMGE4 module The MMGE4 module is a quad-port gigabit interface module. Number Component Color...

  • Page 9: Safety Precautions

    Forcepoint Next Generation Firewall Hardware Guide | Models 110, 115 Precautions The precautions provide safety guidance when working with Forcepoint appliances and electrical equipment. Safety precautions Read the safety information and follow the procedures whenever you are working with electronic equipment.
  • Page 10 Forcepoint Next Generation Firewall Hardware Guide | Models 110, 115 Restricted substances The following table shows the restricted substances and their chemical symbols.
  • Page 11 Forcepoint Next Generation Firewall Hardware Guide | Models 110, 115 Install the appliance Prepare and install the appliance in your network. Before you begin • Install a Security Management Center (SMC) on a separate server. • Configure the Firewall element in the Management Client, and save the initial configuration on a USB drive.

  • Page 12: Connect Cables

    Forcepoint Next Generation Firewall Hardware Guide | Models 110, 115 Push the module into the slot. The module is seated correctly when the front panel of the module is even with the front panel of the appliance. Important: Do not insert the module in the wrong orientation. Inserting the modules incorrectly might damage the appliance and the modules and voids the warranty.
  • Page 13 Forcepoint Next Generation Firewall Hardware Guide | Models 110, 115 Ethernet port mapping For appliances that have removable interface modules, Ethernet port names are based on the slot and port numbers. The first number in the name represents the slot on the appliance, and the second number represents the port on the slot.
  • Page 14 Forcepoint Next Generation Firewall Hardware Guide | Models 110, 115 Figure 2: Changed interface ID mapping Connect network cables Ethernet ports are mapped to interface IDs during the initial configuration. Determine which Ethernet ports to use for connecting to your networks.
  • Page 15 NGFW properly configured and running. When the Forcepoint NGFW engine is in the initial configuration state and no configuration has been saved to the integrated switch, ports in the integrated switch are not configured into port groups and the integrated switch does not yet route traffic.
  • Page 16 Some Forcepoint NGFW appliances ship with replaceable components. Turn off the appliance Most Forcepoint NGFW appliance hardware components are not hot-swappable. Turn off the appliance and disconnect power before replacing the CFast card or interface modules. Note: We recommend fastening a grounding strap to your wrist so that it contacts your bare skin and attaching the other end of the strap to the appliance.
  • Page 17 Forcepoint Next Generation Firewall Hardware Guide | Models 110, 115 Steps Turn off the appliance and disconnect any power cables. Locate the CFast card on your appliance. If there is still tape covering the CFast card, remove the tape. Gently push in the CFast card to release the card from the slot.
  • Page 18 In the network interface configuration options, make sure that the autodetected information is correct and that all interfaces have been detected. If autodetection fails, add network drivers manually. For detailed instructions, see the Forcepoint Next Generation Firewall Installation Guide. If the number of ports in the new module differs from the old module, adjust the mapping of interfaces to interface IDs.
  • Page 19 If needed, insert a replacement SFP transceiver in the slot. Compliance information Forcepoint NGFW appliances that have wireless support are in compliance with certain EU directives and FCC standards for wireless devices intended for home and office use. This information is valid for all dual band products (2.4 GHz, IEEE 802.11b/g/n, and 5 GHz, IEEE 802.11a/n/ac).
  • Page 20 Forcepoint Next Generation Firewall Hardware Guide | Models 110, 115 FCC Standards This appliance is in compliance with FCC Part Applied technologies The appliance uses these technologies. • Radio spectrum — Sub-bands 2400–2483.5 MHz and 5150–5250 MHz • Safety — Dual band products •...
  • Page 21 © 2018 Forcepoint Forcepoint and the FORCEPOINT logo are trademarks of Forcepoint. Raytheon is a registered trademark of Raytheon Company. All other trademarks used in this document are the property of their respective owners.

This manual is also suitable for:

115
