9-3 Touch Menu
Touch
2
TouchScreen
Calibrate
Cursor Cursor
On Off
Lock Lock
On Off
Figure 9-3. Touch Menu
9-4
TouchScreen:
Calibrate: Calibrate the touchscreen if it does not
seem to correctly respond to screen presses. Press
Calibrate (or the 7 key on the keypad) and follow the on
screen instructions to recalibrate the touchscreen. Use
the included touchscreen stylus for the most accurate
results. After the calibration procedure, press Enter to
accept or press Esc to cancel the recalibration.
Cursor: The Site Master includes a screen cursor that
can be controlled with the four directional arrow keys
(#7 in Figure 2-1 on page
Toggle the Touch menu Cursor button to On and press
one of the four directional arrow keys to display the
screen cursor
the 4 arrow keys and use the Enter key for selection.
When a message box is displayed the left or right
arrows keys are used to make a selection.
Note that when the cursor is enabled, the Enter key is
used exclusively for activating the cursor
mouse-up/mouse-down key functions. All other Enter
key functions are disabled.
Lock: When Lock is toggled to On, the touchscreen
will not register user input. The touchscreen would
normally only be locked if it was registering unintended
input that was not resolved with a touchscreen
calibration. This scenario may happen after
touchscreen damage. A lock icon
the top of the screen when Lock is set to On.
To unlock the touchscreen, press Touch (2) to display
the Touchscreen menu and then press the 1 key on the
keypad.
The Site Master can continue to be used to make
measurements and save files even with touchscreen
locked or damaged using a USB mouse or turning on
the Arrow Cursor control.
PN: 10580-00321 Rev. M
2-3) above the keypad.
. Control the cursor movement with
