1-1 Introduction
Chapter 9, "System Operations"
management features of the Site Master including: System menu,
Preset menu, ScrnShot capture, Touch menu, and Help menu.
Chapter 10, "Battery Replacement"
Master batteries.
Chapter 11, "Anritsu Tool Box"
Line Sweep Tools (LST) and easyTest Tools.
Chapter 12, "Video Inspection Probe (VIP)"
condition of a fiber optic termination. A Video Inspection Probe like the
Anritsu Model G0306A must be connected to the instrument.
Appendix A, "Instrument Messages"
messages displayed on the S331L Site Master.

Document Conventions

Main menu and keypad keys are shown in the User Guide in a
Sans Serif Bold typeface. Main menu keys are the six buttons displayed
at the bottom of the interface screen. Submenus and submenu keys are
located on the right side of the trace window and some dialog boxes.
They are shown in this manual in Sans Serif Regular typeface.
Key sequences to access specific Site Master functions are represented
in a manner similar to the following:
Freq/Dist > DTF Setup > Cable List

Additional Documents

The following documents provide additional information about the
Site Master S331L Cable and Antenna Analyzer.
• Handheld Instruments Product Information, Compliance, and
Safety Guide (10100-00065). Provides important safety, legal, and
regulatory notices. Read this guide before operating the
equipment.
• Site Master S331L Technical Data Sheet (11410-00616). Includes
general specifications, detailed measurement specifications for all
available measurement modes, ordering information, and
available accessories.
• Site Master S331L Product Brochure (11410-00640). Includes an
overview of the of the Site Master S331L instrument, ordering
information, and accessories information.
1-2
reviews various instrument
explains how to replace the Site
provides an overview of the Anritsu
provides details regarding
PN: 10580-00321 Rev. M
General Information
is a program used to test the
S331L UG
