www.raisecom.com
ISCOM 1024E User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ISCOM 1024E and is the answer not in the manual?

Questions and answers

Related Manuals for Raisecom ISCOM 1024E

Summary of Contents for Raisecom ISCOM 1024E

  • Page 1 ISCOM 1024E User Manual...

  • Page 2: Legal Notices

    Raisecom Technology Co., Ltd shall not be held liable for errors contained herein or direct, indirect, special, incidental or consequential damages in connection with the furnishing, performance, or use of this material.

  • Page 3: Contact Information

    Floor, South Building of Rainbow Plaza, No.11 Shangdi Information Road, Haidian District, Beijing 100085 Tel: +86-10-82883305 Fax: +86-10-82883056 World Wide Web You can access the most current Raisecom product information on the World Wide Web at the following URL: http://www.raisecom.com...
  • Page 4 FAQ in the related manual, and if your question is not covered, send email by using the following web page: http://www.raisecom.com/en/xcontactus/contactus.htm. If you have comments on the device specification, instead of the web page above, please send comments to: export@raisecom.com...

  • Page 5: Table Of Contents

    CONTENTS Chapter 1 ISCOM 1024E Overview ---------------------------------------------------------------- 1 1.1Package --------------------------------------------------------------------------------------------------------------------------1 Chapter 2 Parameters ---------------------------------------------------------------------------------- 2 2.1 Features: ------------------------------------------------------------------------------------------------------------------------2 2.2 Specifications: ------------------------------------------------------------------------------------------------------------------2 2.3 Environment and power:-----------------------------------------------------------------------------------------------------2 Chapter 3 Mechanical structure and indicators ---------------------------------------------- 3 Chapter 4 configuration and management ------------------------------------------------------ 5 4.1 Manual overview---------------------------------------------------------------------------------------------------------------5...

  • Page 6: About This Manual

    Raisecom RC series integrated access devices, you could find useful information in this manual as well. Compliance The RC series products developed by Raisecom are strictly complied with the following standards as well as ITU-T, IEEE, IETF and related standards from other international telecommunication standard organizations:...
  • Page 7 G.707 Network node interface for the synchronous digital hierarchy (SDH) G.774 Synchronous digital hierarchy (SDH) - Management information model for the network element view G.781 Synchronization layer functions G.783 Characteristics of synchronous digital hierarchy (SDH) equipment functional blocks G.784 Synchronous digital hierarchy (SDH) management G.803 Architecture of transport networks based on the synchronous digital hierarchy (SDH) G.813 Timing characteristics of SDH equipment slave clocks (SEC) G.823 The control of jitter and wander within digital networks which are based on the 2048 kbit/s...

  • Page 8: Chapter 1 Iscom 1024E Overview

    Chapter 1 ISCOM 1024E Overview ISCOM 1024E is an Ethernet switch with VLAN and QOS. It can provide 24X10/100Mbps RJ45 interfaces and support Local craft terminal management through Console, Port-Based VLAN and 802.1q VLAN, Port-Based QOS, Tag-Based QOS and TOS-Based QOS, support abundant port managed and loop back detection function.

  • Page 9: Chapter 2 Parameters

    User Manual Chapter 2 Parameters 2.1 Features: 24x10/100Mbps RJ45 interface It supports MDI or MDI-X It supports CONSOLE local management Bi-directional Nx32Kbps bandwidth management Port rate limiting, Based on ingress and egress of each port, 8 levels QoS: Support IEEE802.1p and DSCP classification, Port-based CoS...

  • Page 10: Chapter 3 Mechanical Structure And Indicators

    User Manual Chapter 3 Mechanical structure and indicators The front panel of ISCOM1024E contains 24 10/100Mbps RJ45 interface, 1 console port and LED. Switch logo and type: ISCOM1024E Console management 24 10/100Mbps RJ45 interface 2 LED SYS and PWR...
  • Page 11 User Manual Rear panel provide 220V AC power as follows:...

  • Page 12: Configuration And Management

    There is no network connect for network managed program network managed program do not support SNMP ISCOM 1024E default setting as [bits per second: 9600, data bits: 8, Parity: 0, stop bits: 1, flow control: None], VT100 type terminal. Log on ISCOM 1024E Default password is 1234.
  • Page 13 User Manual Select the item through numeric key on this interface. 4.2.2 PORT SETUP Select “1” to enter the screen as following in the main manual. Modify setting Press “m” to modify the setting including：Admin(e：open，d：close)、Auto(e：auto negotiation，d：non auto negotiation)、speed (1：100M，0：10M)、Duplex(f：full，h：half)、flow-C(e：enable flow control，d：disable flow control).
  • Page 14 User Manual After modification, Press “q” to quit and return main manual, press “y” to save, press “n” not to save. Note: when the auto negotiation is enabled, state of local port is associate with connected port, speed and duplex are invalid.
  • Page 15 User Manual Select ‘2’: set Uplink Based-Port VLAN Select ‘3’: system will ask user to set VLAN port manually Select ‘4’: delete all the VLAN Note: IPTV VLAN will disappear if you set other Port VLAN 4.2.4 Set 802.1q VLAN Note: Port VLAN should be deleted before you create 802.1Q VLAN...
  • Page 16 Select ‘2’ to modify VLAN area, input ‘m’ to modify the menu of VLAN area, Select GroupNO: ‘0’ (ISCOM 1024E can only support 0~31 VLAN groups. Such as for the first VLAN, ID is 0). Select add or remove port, then select port ID, enter ‘q’ to save.
  • Page 17 User Manual Select ‘4’ to set tag port and PVID Note: when the VLAN area is created, PVID will be the same as VAN ID, it is suggest that user keep the default value. User can select ‘tag’ or ‘untag’ according to the requirement.

  • Page 18: Advanced Configuration

    User Manual Select ‘1’ to set flow scale Select ‘2’ to set priority for each port Select ‘3’ set IEEE802.1P service Select ‘4’ set TOS/DeffServ based priority Select ‘5’ back to previous menu Note: priority for QOS is COS, QOS and port.

  • Page 19: Loopback Detection

    User Manual Note: enable Broadcast storm filtering, p ort will stop receiving when the first 64 packets have been received, but it will receive packet again after 800s. Age time is less than 300s, fast age time is 12s.

  • Page 20: Link Aggregation

    User Manual 4.2.6.2 Link aggregation Select ‘4’ in advanced menu to set link aggregation. ISCOM1024E Support 6 trunk groups,There can be 4 ports in each trunk group. For example: enable trunk 1, disable trunk 2~6 e: enable trunk d: disable trunk 4.2.6.3 Mirror...

  • Page 21: System Configuration

    User Manual TX Miror Port (1-24,q)6 select a port, which output is mirrored. Enable/Disble TX Mirror(e/d)? e whether mirror output of port TX Miror Port (1-24,q) press ‘q’ if you do not select the port which output is mirrored.

  • Page 22: Chapter 5 Network Connection

    Chapter 5 Network Connection 5.1 Connect ISCOM 1024E Use UTP3 or UTP5 to connect 10BaseT with ISCOM 1024E Use UTP5 to connect 100BaseT with ISCOM 1024E The cable should not more than 100m in IEEE stander. 5.2 Connect ISCOM1024E with other Ethernet switch or HUB ISCOM1024E can connect other 10/100switch, Support MDI or MDI-X.

  • Page 23: Chapter 6 Placed Iscom1024E

    User Manual Chapter 6 laced ISCOM1024E ISCOM1024 can be placed on a desk or other plane. 6.1 Placed ISCOM1024E on a desk Put ISCOM1024E on a desk, connect a cable with ISCOM1024E...

  • Page 24: Chapter 7 Trouble Shooting

    Chapter 7 Trouble shooting 7.1 How to resolve link LED off The possible reasons are following: the power supply is off the type of cable is not right one physical interface of switch has some problem environment, such as building 7.2 Q &...

  • Page 25: Chapter 8 Cable

    Chapter 8 Cable A There are two kinds of cable Straight-through Cross-over 1) Straight through cable (The straight through cable for 100M or 1000M are identical.) Side 1 Side 1 Side 2 3 5 7 1 = White/Orange 1 = White/Orange 2 = Orange 2 = Orange 3 = White/Green...
  • Page 26 manage the switch through PC. The CONSOLE interface of ISCOM1024E is in the form of RJ-45. The RJ-45 connector and jack and the corresponding pin number is shown in the figure below. RJ-45 Connector RJ-45 Jack The corresponding pin function definition of ISCOM1024E CONSOLE interface is shown in the table below: Pin Number Function Type...
  • Page 27 2) CONSOLE interface connecting pattern and parameter setup The connecting of ISCOM1024E CONSOLE interface and PC serial port is shown in the figure below. 4、5 PC Serial Pot CONSOLE...
