Summary of Contents for Raisecom ISCOM2600G (A) Series

  • Page 1 ISCOM2600G (A) Series Product Description (Rel_10)
  • Page 2 Website: http://www.raisecom.com Tel: 8610-82883305 Fax: 8610-82883056 Email: export@raisecom.com Address: Raisecom Building, No. 11, East Area, No. 10 Block, East Xibeiwang Road, Haidian District, Beijing, P.R.China Postal code: 100094 ----------------------------------------------------------------------------------------------------------------------------------------- Notice Copyright ©2019 Raisecom All rights reserved.
  • Page 3 Raisecom ISCOM2600G (A) Series Product Description Preface Preface Objectives This document describes the ISCOM2600G series switches in terms of product overview, networking applications, system structure, device installation, and technical specifications. The appendix describes cables and SFP modules, and lists terms, acronyms, and abbreviations involved in this document.
  • Page 4 Raisecom ISCOM2600G (A) Series Product Description Preface Symbol Description Indicate a hazard with a medium or low level of risk which, if not avoided, could result in minor or moderate injury. Indicate a potentially hazardous situation that, if not avoided, could cause equipment damage, data loss, and performance degradation, or unexpected results.
  • Page 5 Raisecom ISCOM2600G (A) Series Product Description Preface Issue 08 (2018-05-14) Eighth commercial release  Added the ISCOM2624G-4C-PWR. Issue 07 (2017-06-30) Seventh commercial release  Added the ISCOM2648G-4C-AC_DC. Issue 06 (2016-11-15) Sixth commercial release  Added the ISCOM2624G-4GE-RPS and ISCOM2648G-4GE-RPS. Issue 05 (2016-05-15) Fifth commercial release ...

  • Page 6: Table Of Contents

    Raisecom ISCOM2600G (A) Series Product Description Contents Contents 1 Overview ............................1 1.1 Introduction ..............................1 1.2 Features ................................1 1.3 Ordering information............................3 1.3.1 Naming convention ..........................3 1.3.2 Ordering information about device ......................4 1.3.3 Ordering information about auxiliary parts ..................... 8 2 Networking applications ......................
  • Page 7 Raisecom ISCOM2600G (A) Series Product Description Contents 4 Device installation ........................48 4.1 Installing hardware ............................48 4.1.1 Preparing for installation ........................48 4.1.2 Installing device ............................ 49 4.1.3 Connecting cables ..........................53 4.2 Installing software ............................56 5 Technical specifications ......................57 5.1 Overall parameters ............................
  • Page 8 Raisecom ISCOM2600G (A) Series Product Description Figures Figures Figure 1-1 Naming convention ..........................3 Figure 2-1 Enterprise park network access networking ..................14 Figure 2-2 Residential area broadband access networking................... 15 Figure 3-1 Front panel of ISCOM2608G-2GE-AC ....................17 Figure 3-2 Front panel of ISCOM2608G-2GE-DC ....................17 Figure 3-3 Front panel of ISCOM2608G-2GE-PWR-AC ..................
  • Page 9 Raisecom ISCOM2600G (A) Series Product Description Figures Figure 3-24 Rear panel of ISCOM2624G-4GE-RPS-AC ..................26 Figure 3-25 Rear panel of ISCOM2624G-4C-AC/DC ..................26 Figure 3-26 Rear panel of ISCOM2648G-4GE-AC ..................... 27 Figure 3-27 Rear panel of ISCOM2648G-4GE-DC ..................... 27 Figure 3-28 Rear panel of the ISCOM2648G-4GE-RPS-AC................27 Figure 3-29 Rear panel of the ISCOM2648G-4C-AC/S ..................
  • Page 10 Raisecom ISCOM2600G (A) Series Product Description Figures Figure 6-6 Ground cable ............................70 Figure 6-7 OT terminal ............................70 Figure 6-8 DC power cable ..........................71 Figure 6-9 European AC power cable ........................73 Figure 6-10 American AC power cable ........................ 73 Figure 6-11 RJ45 Console cable...........................
  • Page 11 Raisecom ISCOM2600G (A) Series Product Description Tables Tables Table 1-1 Features ..............................1 Table 1-2 Naming convention ..........................3 Table 1-3 Ordering information about device ......................4 Table 1-4 Ordering information about RPS power supply ..................8 Table 1-5 Ordering information about accessories ....................9 Table 1-6 Ordering information about wall-mount accessories................
  • Page 12 Raisecom ISCOM2600G (A) Series Product Description Tables Table 3-16 LEDs on ISCOM2624G-4GE ......................40 Table 3-17 LEDs on ISCOM2624G-4GE-PWR ....................41 Table 3-18 LEDs on the ISCOM2624G-4GE-RPS ....................42 Table 3-19 LEDs on ISCOM2624G-4C ....................... 42 Table 3-20 LEDs on ISCOM2624G-4C-PWR ..................... 43 Table 3-21 LEDs on ISCOM2648G-4GE ......................

  • Page 13: Overview

    Features  Ordering information 1.1 Introduction The Raisecom-developed 1000 Mbit/s Ethernet switch ISCOM2600G series switch, which meets the requirements of all-1000 Mbit/s access, is designed for the access layer and can be used as aggregation devices for enterprises. 1.2 Features Table 1-1 lists features of the ISCOM2600G series switch.
  • Page 14 Raisecom ISCOM2600G (A) Series Product Description 1 Overview Feature Description  MAC management and port security MAC Ethernet  VLAN (4094 VLANs)  Private VLAN  VLAN IP interface  QinQ  VLAN mapping  Loopback detection  Interface protection ...

  • Page 15: Ordering Information

    Raisecom ISCOM2600G (A) Series Product Description 1 Overview Feature Description  Link aggregation Reliability  Interface backup  G.8032 IEEE 802.3ah  SNMP System management  KeepAlive  RMON  LLDP   System log  Alarm management  Fan monitoring ...

  • Page 16: Ordering Information About Device

    Raisecom ISCOM2600G (A) Series Product Description 1 Overview Domain Indication Value Description Product ID ISCOM Raisecom ISCOM series device Subtype and One of the 2600 series number of  8: provide 8 downlink interfaces. interfaces 8/24/48  24: provide 24 downlink interfaces.
  • Page 17 Raisecom ISCOM2600G (A) Series Product Description 1 Overview Model Description  Support eight 10/100/1000 Mbit/s RJ45 downlink interfaces. ISCOM2608G-  Support two 1000 Mbit/s Combo interfaces (SFP 100/1000Base-X 2GE-DC interface and RJ45 10/100/1000Base-T interface, which cannot be enabled concurrently). ...
  • Page 18 Raisecom ISCOM2600G (A) Series Product Description 1 Overview Model Description  Support twenty-four 10/100/1000 Mbit/s RJ45 downlink interfaces. ISCOM2624G-  Support four 1000 Mbit/s Combo interfaces (SFP 100/1000Base-X 4GE-PWR interface and RJ45 10/100/1000Base-T interface, which cannot be enabled concurrently). ...
  • Page 19 Raisecom ISCOM2600G (A) Series Product Description 1 Overview Model Description  Support twenty-four 10/100/1000 Mbit/s RJ45 downlink interfaces. ISCOM2624G-  Support four 10 Gbit/s SFP+ uplink interfaces (it also supports 1000 4C-PWR-AC Mbit/s SFP modules).  Support the SNMP interface for out-of-band network management.

  • Page 20: Ordering Information About Auxiliary Parts

    Raisecom ISCOM2600G (A) Series Product Description 1 Overview Model Description  Support forty-eight 10/100/1000 Mbit/s RJ45 downlink interfaces. ISCOM2648G-  Support four 10 Gbit/s SFP+ uplink interfaces (it also supports 1000 4C-DC/S Mbit/s SFP modules).  Support the SNMP interface for out-of-band network management.

  • Page 21: Table 1-5 Ordering Information About Accessories

    Raisecom ISCOM2600G (A) Series Product Description 1 Overview Installing accessories Table 1-5 lists ordering information about the accessories. Table 1-5 Ordering information about accessories ERP code Name Quantity 20.08.03.0042.01 RC953-4FE4E1T1 series corner (customized for the 19'' rack) 20.08.03.0047.01 ISCOM5104 (B) corner (customized for the 19'' rack) 20.04.00.0007.02...

  • Page 22: Table 1-8 Ordering Information About 100 Mbit/S Sfp Electrical Module

    Raisecom ISCOM2600G (A) Series Product Description 1 Overview Model Description  Transmission rate: 155 Mbit/s USFP-03/S2-D-R/SW  Target transmission distance: 40 km  Tx wavelength: 1310 nm  Dual-fiber SM SFP optical module   RoHS-compliant  Transmission rate: 155 Mbit/s USFP-03/S3-D-R/SW ...

  • Page 23: Table 1-10 Ordering Information About 1000 Mbit/S Sfp Electrical Module

    Raisecom ISCOM2600G (A) Series Product Description 1 Overview Model Description  Transmission rate: 1.25 Gbit/s USFP-Gb/S2-D-  Target transmission distance: 40 km R/SW  Tx wavelength: 1550 nm  Dual-fiber SM SFP optical module   RoHS-compliant  Transmission rate: 1.25 Gbit/s USFP-Gb/S3-D- ...
  • Page 24 Raisecom ISCOM2600G (A) Series Product Description 1 Overview Model Description  Transmission rate: 10 Gbit/s USFP+-192/S1/SW  Target transmission distance: 10 km  Tx wavelength: 1310 nm  Dual-fiber SM SFP+ optical module   RoHS-compliant  SFP+ optical module USFP+-192/S2/SW ...

  • Page 25: Networking Applications

    Raisecom ISCOM2600G (A) Series Product Description 2 Networking applications Networking applications This chapter describes typical networking applications of the ISCOM2600G series switch, including the following sections:  Enterprise park network access  Residential area broadband access 2.1 Enterprise park network access...

  • Page 26: Residential Area Broadband Access

    Raisecom ISCOM2600G (A) Series Product Description 2 Networking applications Figure 2-1 Enterprise park network access networking 2.2 Residential area broadband access As an access switch, the ISCOM2600G series switch can work as a core switch for a small network. As shown in Figure 2-2, the ISCOM2600G series switch is connected to the L3 aggregation switch through the 10GE interface and downstream to the 1000 Mbit/s switch through the GE interface.

  • Page 27: Figure 2-2 Residential Area Broadband Access Networking

    Raisecom ISCOM2600G (A) Series Product Description 2 Networking applications Figure 2-2 Residential area broadband access networking Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.

  • Page 28: System Structure

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure System structure This chapter describes system structure of the ISCOM2600G series switch, including the following sections:  Panels  Interfaces  Power interfaces  LEDs 3.1 Panels Definition of the power supply is listed below: ...

  • Page 29: Figure 3-1 Front Panel Of Iscom2608G-2Ge-Ac

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure Figure 3-1 Front panel of ISCOM2608G-2GE-AC Ground terminal Power interface Service interfaces (1–8) LEDs Service downlink interfaces (1–8) Service uplink SFP optical interfaces (9–10) Service uplink GE interfaces (9–10) SNMP interface and Console interface...

  • Page 30: Figure 3-3 Front Panel Of Iscom2608G-2Ge-Pwr-Ac

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure Figure 3-3 Front panel of ISCOM2608G-2GE-PWR-AC Power interface Power switch Service interfaces (1–8) and LEDs Uplink interface LEDs Service uplink SFP optical interfaces (9–10) Service uplink GE interfaces (9–10) SNMP interface and Console interface...

  • Page 31: Figure 3-5 Front Panel Of Iscom2624G-4C-Pwr-Ac/Dc

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure Figure 3-5 Front panel of ISCOM2624G-4C-PWR-AC/DC Service downlink interfaces (1–24) Service uplink SFP optical interfaces (25–28) SNMP interface and Console interface Interface LEDs POE, SNMP, SYS, and PWR LEDs Mode button (PoE mode switching) ISCOM2624G-4GE-AC Figure 3-6 shows the front panel of the ISCOM2624G-4GE-AC.

  • Page 32: Figure 3-8 Front Panel Of Iscom2624G-4Ge-Pwr-Ac/Dc

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure Ground terminal Power interface Service interfaces (1–28) LEDs Service downlink interfaces (1–24) Service uplink GE interfaces (25–28) Service uplink SFP optical interfaces (25–28) SNMP interface and Console interface PWR, SYS, and SNMP LEDs ISCOM2624G-4GE-PWR-AC/DC Figure 3-8 shows the front panel of the ISCOM2624G-4GE-PWR-AC/DC.

  • Page 33: Figure 3-10 Front Panel Of The Iscom2624G-4C-Ac

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure SNMP interface and Console interface RPS, PWR, SYS, and SNMP LEDs ISCOM2624G-4C-AC Figure 3-10 shows the front panel of the ISCOM2624G-4C-AC. Figure 3-10 Front panel of the ISCOM2624G-4C-AC Ground terminal Power interface Service interfaces (1–28) LEDs...

  • Page 34: Figure 3-12 Front Panel Of The Iscom2648G-4Ge-Ac/Dc

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure ISCOM2648G-4GE-AC/DC Figure 3-12 shows the front panel of the ISCOM2648G-4GE-AC/DC. Figure 3-12 Front panel of the ISCOM2648G-4GE-AC/DC Service downlink interfaces (1–48) and LEDs Service uplink SFP optical interfaces (49–52) Service uplink GE interfaces (49–52) LEDs ISCOM2648G-4GE-RPS-AC Figure 3-13 shows the front panel of the ISCOM2648G-4GE-RPS-AC.

  • Page 35: Figure 3-14 Front Panel Of The Iscom2648G-4C-Ac/Dc/S

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure Figure 3-14 Front panel of the ISCOM2648G-4C-AC/DC/S Service downlink interfaces (1–48) and LEDs Service uplink SFP optical interfaces (49–52) Uplink interfaces, SNMP interface, SYS, and SNMP interface and Console interface PWR1/PWR2 ISCOM2648G-4C-AC/DC/D Figure 3-15 shows the front panel of the ISCOM2648G-4C-AC/DC/D.

  • Page 36: Rear Panels

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure Service downlink interfaces (1–48) and LEDs Service uplink SFP optical interfaces (49–52) Uplink interfaces, SNMP interface, SYS, and SNMP interface and Console interface PWR1/PWR2 3.1.2 Rear panels ISCOM2608G-2GE-AC/DC Figure 3-17 shows the rear panel of the ISCOM2608G-2GE-AC/DC.

  • Page 37: Figure 3-20 Rear Panel Of Iscom2624G-4C-Pwr-Dc

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure ISCOM2624G-4C-PWR-DC Take the AC model for example. Figure 3-20 shows the rear panel of the ISCOM2624G-4C- PWR-DC. Figure 3-20 Rear panel of ISCOM2624G-4C-PWR-DC Ground terminal Power switch Power interface ISCOM2624G-4GE-AC/DC Figure 3-18 shows the rear panel of the ISCOM2624G-4GE-AC/DC.

  • Page 38: Figure 3-23 Rear Panel Of Iscom2624G-4Ge-Pwr-Dc

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure ISCOM2624G-4GE-PWR-DC Take the AC model for example. Figure 3-20 shows the rear panel of the ISCOM2624G-4GE- PWR-DC. Figure 3-23 Rear panel of ISCOM2624G-4GE-PWR-DC Ground terminal Power switch Power interface ISCOM2624G-4GE-RPS-AC Take the AC model for example. Figure 3-24 shows the rear panel of the ISCOM2624G-4GE- RPS-AC.

  • Page 39: Figure 3-26 Rear Panel Of Iscom2648G-4Ge-Ac

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure Figure 3-26 Rear panel of ISCOM2648G-4GE-AC Power interface Ground terminal SNMP interface and Console interface SNMP, SYS, and PWR LEDs ISCOM2648G-4GE-DC Figure 3-27 shows the rear panel of the ISCOM2648G-4GE-DC. Figure 3-27 Rear panel of ISCOM2648G-4GE-DC...

  • Page 40: Figure 3-29 Rear Panel Of The Iscom2648G-4C-Ac/S

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure ISCOM2648G-4C-AC/S Figure 3-29 shows the rear panel of the ISCOM2648G-4C-AC/S. Figure 3-29 Rear panel of the ISCOM2648G-4C-AC/S Ground terminal Power interface ISCOM2648G-4C-DC/S Figure 3-30 shows the rear panel of the ISCOM2648G-4C-DC/S.

  • Page 41: Interfaces

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure Ground terminal Power interface ISCOM2648G-4C-DC/D Figure 3-32 shows the rear panel of the ISCOM2648G-4C-DC/D. Figure 3-32 Rear panel of the ISCOM2648G-4C-DC/D Ground terminal Power interface ISCOM2648G-4C-AC_DC Figure 3-33 shows the rear panel of the ISCOM2648G-4C-AC_DC.

  • Page 42: Table 3-1 Service Interfaces

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure Table 3-1 Service interfaces Interface Quantity Description Uplink ISCOM2608G-2GE 1000 Mbit/s Combo interface interfaces The SFP interface supports the following SFP optical modules:  1000BASE-X  100BASE-FX The SFP interface supports the following SFP electrical modules: ...
  • Page 43 Raisecom ISCOM2600G (A) Series Product Description 3 System structure Interface Quantity Description ISCOM2624G-4GE- 1000 Mbit/s Combo interface The SFP interface supports the following SFP optical modules:  1000BASE-X  100BASE-FX The SFP interface supports the following SFP electrical module: ...
  • Page 44 Raisecom ISCOM2600G (A) Series Product Description 3 System structure Interface Quantity Description ISCOM2648G-4GE 1000 Mbit/s Combo interface The SFP interface supports the following SFP optical modules:  1000BASE-X  100BASE-FX The SFP interface supports the following SFP electrical module: ...

  • Page 45: Table 3-2 Parameters Of 10 Gbit/S Sfp+ Optical Interface

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure Interface Quantity Description ISCOM2624G-4GE 10/100/1000BASE-T adaptive electrical interface ISCOM2624G-4GE- 10/100/1000BASE-T adaptive electrical interface  Support supplying power for the remote PD through PoE.  Support up to 30 W output power per interface.

  • Page 46: Table 3-3 Parameters Of 1000 Mbit/S Sfp Optical Interface

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure 1000 Mbit/s SFP optical interface Table 3-3 lists parameters of the 1000 Mbit/s SFP optical interface. Table 3-3 Parameters of 1000 Mbit/s SFP optical interface Parameter Description Connector type LC/PC Optical interface properties Depend on the selected SFP optical module.

  • Page 47: Management Interfaces

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure 3.2.2 Management interfaces Table 3-6 lists types and usage of management interfaces on the ISCOM2600G series switch. Table 3-6 Management interfaces Interface Description Local management and control interface. You can log in to the...

  • Page 48: Power Interfaces

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure 3.3 Power interfaces 3.3.1 DC power Introduction The DC power supply provides -48 VDC power. Interface There is a DC power input interface for inputting DC power on the panel of the ISCO2600 series switch, as shown in Figure 3-34.

  • Page 49: Rps Power Interface

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure  Supply 220 VAC power supply.  Support a lightning protection level of 6 kV in both common mode and differential mode. Interfaces There is an AC power input interface for inputting AC power on the panel of the ISCO2600 series switch, as shown in Figure 3-35.

  • Page 50: Leds

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure Figure 3-37 ISCOM2648G-4GE-RPS-AC power interface Table 3-12 lists details about the RPS power interface. Table 3-12 Details about the RPS power interface Interface Type Print Usage RPS power 3-pin Phoenix GND power input terminal...

  • Page 51: Iscom2608G-2Ge-Pwr

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure Status Description LNK/ACT Green Combo interface working status LED 9–10  Green: the interface is properly connected.  Blinking green: the interface is receiving or sending data.  Off: the interface is disconnected or improperly connected.

  • Page 52: Iscom2624G-4Ge

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure Status Description SNMP Green SNMP interface working status LED  Green: the SNMP interface is properly connected.  Blinking green: the SNMP interface is receiving or sending data.  Off: the SNMP interface is disconnected or improperly connected.

  • Page 53: Iscom2624G-4Ge-Pwr

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure 3.4.4 ISCOM2624G-4GE-PWR Table 3-16 lists LEDs on the ISCOM2624G-4GE-PWR. Table 3-17 LEDs on ISCOM2624G-4GE-PWR Status Description LNK/ACT Green Ethernet interface working status LED  1–24 Green: the interface is properly connected.

  • Page 54: Iscom2624G-4C

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure Table 3-18 LEDs on the ISCOM2624G-4GE-RPS Status Description LNK/ACT Green Ethernet interface working status LED Port1–Port24  Green: the interface is properly connected.  Blinking green: the interface is receiving or sending data.

  • Page 55: Iscom2624G-4C-Pwr

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure Status Description Green Power working status LED  Green: the power supply is normal.  Off: the power supply is off or the power module is improperly installed. SNMP Green SNMP interface working status LED ...

  • Page 56: Iscom2648G-4Ge

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure Status Description SNMP Green SNMP interface working status LED  Green: the SNMP interface is properly connected.  Blinking green: the SNMP interface is receiving or sending data.  Off: the SNMP interface is disconnected or improperly connected.

  • Page 57: Iscom2648G-4Ge-Rps

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure Status Description SNMP Green SNMP interface working status LED  Green: the SNMP interface is properly connected.  Blinking green: the SNMP interface is receiving or sending data.  Off: the SNMP interface is disconnected or improperly connected.

  • Page 58: Iscom2648G-4C

    Raisecom ISCOM2600G (A) Series Product Description 3 System structure Status Description Green System working LED  Green: the system is working improperly.  Blinking green (every 1s): the system has loaded the configuration file or the device is configured. ...
  • Page 59 Raisecom ISCOM2600G (A) Series Product Description 3 System structure The 24 Ethernet electrical interfaces, numbered 1–24, on the ISCOM2624G-4GE- PWR and ISCOM2624G-4C-PWR are all PoE interfaces. Each interface corresponds to one LED which displays the LNK/ACT or PoE power supply status in different modes.

  • Page 60: Device Installation

    Raisecom ISCOM2600G (A) Series Product Description 4 Device installation Device installation This chapter describes how to install the ISCOM2600G series switch, including the following sections:  Installing hardware  Installing software 4.1 Installing hardware The ISCOM2600G series switch adopts a 1U cartridge structure. It can be easily installed in the following scenarios of a telecom equipment room: ...

  • Page 61: Installing Device

    Raisecom ISCOM2600G (A) Series Product Description 4 Device installation When the altitude is from 1800m to 5000m, every time the altitude is increased by 220 m, the maximum operating temperature of the equipment will be decreased by 1° C. Power supply conditions Table 4-2 lists power supply requirements on the operation of the ISCOM2600G series switch.

  • Page 62: Figure 4-1 Installing Brackets

    Raisecom ISCOM2600G (A) Series Product Description 4 Device installation ISCOM2608G-2GE-PWR adopt the non-standard 1U chassis. If you wish to install them in a rack, buy the customized 19'' brackets additionally. The brackets, which are only for positioning, cannot bear the weight of the device.

  • Page 63: Figure 4-3 Installing Guide Rails

    Raisecom ISCOM2600G (A) Series Product Description 4 Device installation Figure 4-3 Installing guide rails Step 5 Use screws to fix two customized brackets to guide rail, and install the ISCOM2648G-4C horizontally in the rack, as shown in Figure 4-4. Figure 4-4 Installing device horizontally in rack Do not lay heavy objects or coverings on the ISCOM2600G series switch.

  • Page 64: Figure 4-5 Installing Wall-Mount Brackets

    Raisecom ISCOM2600G (A) Series Product Description 4 Device installation Step 1 Choose a proper wall-mount height where you can easily observe the LEDs and connect the power supply. Step 2 Use the M3*6 screws to install the wall-mount brackets to the two sides of the device (Figure 4-5 shows how to install brackets to one side.

  • Page 65: Connecting Cables

    Raisecom ISCOM2600G (A) Series Product Description 4 Device installation Figure 4-7 Wall-mount installation Step 5 Swing the device using proper strength to see whether it is secured. 4.1.3 Connecting cables Connecting fiber There is invisible laser which harms eyes inside the ISCOM2600G series switch. Do not stare into the optical interface, fiber connector, or breakage of fiber directly.

  • Page 66: Figure 4-9 Connecting Fiber

    Raisecom ISCOM2600G (A) Series Product Description 4 Device installation Figure 4-9 Connecting fiber  Figure 4-9 takes the 1000 Mbit/s SFP optical module for example. The connection of the 10 Gbit/s SFP+ optical module is identical.  When the optical interface is idle, cover it with a dustproof cap to prevent dust and dirt which may make the ISCOM2600G series switch work improperly.

  • Page 67: Figure 4-11 Connecting Ground Cable

    Raisecom ISCOM2600G (A) Series Product Description 4 Device installation Step 3 Reinstall the screw to the ground terminal, and tighten the screws clockwise, as shown in Figure 4-11. Figure 4-11 Connecting ground cable Connecting AC power cable Connect the AC power cable as below: Step 1 Ensure that the ISCOM2600G series switch is well grounded.

  • Page 68: Installing Software

    Raisecom ISCOM2600G (A) Series Product Description 4 Device installation Figure 4-13 Connecting DC power cable Step 4 Connect the other end of the DC power cable to the power sourcing equipment in the equipment room. Connecting RJ45 Console cable Install the RJ45 Console cable as below: Step 1 Insert the RJ45 connector of the RJ45 Console cable into the Console interface on the ISCOM2600G series switch.

  • Page 69: Technical Specifications

    Raisecom ISCOM2600G (A) Series Product Description 5 Technical specifications Technical specifications This chapter describes overall parameters, system parameters, card parameters, and technical specifications, including the following sections:  Overall parameters  Laser safety class  Reliability specifications  EMC indexes ...
  • Page 70 Raisecom ISCOM2600G (A) Series Product Description 5 Technical specifications Parameter Description (Depth) × 44 (Height)  ISCOM2648G-4C: 440 (Width) × 300 (Depth) × 44 (Height)  ISCOM2608G-2GE: 15 Overall power consumption (W)  ISCOM2608G-2GE-PWR: up to 141, the PoE interface supplies power up to 124.

  • Page 71: Laser Safety Class

    Raisecom ISCOM2600G (A) Series Product Description 5 Technical specifications Parameter Description  ISCOM2624G-4C: 6 kV in differential mode, 6 kV in common mode  ISCOM2624G-4C-PWR: 6 kV in differential mode, 6 kV in common mode  ISCOM2648G-4GE: 6 kV in differential mode, 6 kV in common mode ...

  • Page 72: Reliability Specifications

    Raisecom ISCOM2600G (A) Series Product Description 5 Technical specifications The laser inside fiber may hurt your eyes. Do not stare into the optical interface directly during installation and maintenance. 5.3 Reliability specifications Table 5-3 lists reliability specifications of the ISCOM2600G series switch.

  • Page 73: Environmental Requirements

    Raisecom ISCOM2600G (A) Series Product Description 5 Technical specifications 5.6 Environmental requirements The ISCOM2600G series switch complies with the following environmental requirements:  GF 014-1995: telecommunication equipment room conditions  NEBS GR-63-CORE: Network Equipment-Building System (NEBS) Requirements: Physical Protection ...

  • Page 74: Transport Environment

    Raisecom ISCOM2600G (A) Series Product Description 5 Technical specifications  Rodent animals, such as rats 5.6.2 Transport environment Atmosphere environment Table 5-5 lists atmosphere requirements for the ISCOM2600G series switch during transport. Table 5-5 Atmosphere requirements during transport Parameter Description Air pressure (kPa) 86–106...

  • Page 75: Standards And Protocols

    Raisecom ISCOM2600G (A) Series Product Description 5 Technical specifications Parameter Description Relative humidity 10%–90% (non-condensing) ≤ 0.5 Temperature change rate (° C/min) ≤ 700 Solar radiation (W/s² ) ≤ 600 Heat radiation (W/s² ) ≤ 5 Wind speed (m/s) Biotic environment Keep the ISCOM2600G series switch away from: ...
  • Page 76 Raisecom ISCOM2600G (A) Series Product Description 5 Technical specifications  ITU-T G.8031 Ethernet linear protection switching  ITU-T G.8032 Ethernet ring protection switching  ITU-T G.8261 Timing and Synchronization Aspects in Packet Networks  ITU-T G.8262 Timing Characteristics of Synchronous Ethernet Equipment Slave Clock (EEC) ...

  • Page 77: Appendix

    Raisecom ISCOM2600G (A) Series Product Description 6 Appendix Appendix The appendix lists cables, SFP modules, terms, acronyms, and abbreviations, including the following sections:  Cables  SFP modules  Terms  Acronyms and abbreviations 6.1 Cables The following cables are used when connecting the ISCOM2600G series switch: ...

  • Page 78: Figure 6-1 Lc/Pc Fiber Connector

    Raisecom ISCOM2600G (A) Series Product Description 6 Appendix Local connector Remote connector Fiber FC/PC 2 mm SMF 2 mm MMF SC/PC 2 mm SMF 2 mm MMF Choose the fiber connector properly as required on site. Otherwise, extra fiber loss will occur, service transmission will be deteriorated, and even the fiber connector and interface may be damaged.

  • Page 79: Ethernet Cable

    Raisecom ISCOM2600G (A) Series Product Description 6 Appendix Wiring Optical interface on Direction of optical Optical interface on local device signals peer device Dual-fiber Tx optical interface -> Rx optical interface wiring Rx optical interface <- Tx optical interface 6.1.2 Ethernet cable...

  • Page 80: Figure 6-3 Wiring Of 10/100/1000 Mbit/S Straight-Through Cable

    Raisecom ISCOM2600G (A) Series Product Description 6 Appendix Connector (RJ45) EIA/TIA 568A EIA/TIA 568B PIN 5 White/Blue White/Blue PIN 6 Orange Green PIN 7 White/Brown White/Brown PIN 8 Brown Brown Both two RJ45 connectors of the 10/100/1000 Mbit/s straight-through cable follow EIA/TIA568B standard wiring.

  • Page 81: Figure 6-4 Wiring Of 100 Mbit/S Crossover Cable

    Raisecom ISCOM2600G (A) Series Product Description 6 Appendix Figure 6-4 Wiring of 100 Mbit/s crossover cable Figure 6-5 shows wiring of 1000 Mbit/s crossover cable. Figure 6-5 Wiring of 1000 Mbit/s crossover cable Technical specifications Table 6-4 lists technical specifications of the Ethernet cable.

  • Page 82: Ground Cable

    Raisecom ISCOM2600G (A) Series Product Description 6 Appendix Parameter Description Connector RJ45 crystal header Model Cat 5 or better UTP (UTP-5 or UTP-5e) or Cat 5e STP cable Number of cores Length The letter D is the length, which can be customized. For example, if the customer requires 2-meter cables, you can name it CBL-ETH- RJ45/RJ45-2m.

  • Page 83: Dc Power Cable

    Raisecom ISCOM2600G (A) Series Product Description 6 Appendix Inner diameter of Inner diameter of 3 Thickness of soldering terminal soldering lug sheath Technical specifications Table 6-5 lists technical specifications of the ground cable. Table 6-5 Technical specifications of ground cable...

  • Page 84: Ac Power Cable

    Raisecom ISCOM2600G (A) Series Product Description 6 Appendix Table 6-6 Technical specifications of DC power cable Parameter Description Name POL-DC (2 cores)-stripped wire/U-type terminal- 0.75 mm -1.5 m/RoHS Connector U-type terminal (flame-retardant tube)  2-core PVC-sheathed cord Cable  2 × 0.75mm 60227 IEC 53 (RVV) ...

  • Page 85: Figure 6-9 European Ac Power Cable

    Raisecom ISCOM2600G (A) Series Product Description 6 Appendix Figure 6-9 European AC power cable The AC power cable which meets American standard is composed of the American 3-pin plug and C13 connector, as shown in Figure 6-10. Figure 6-10 American AC power cable Technical specifications Table 6-8 lists technical specifications of the European AC power cable.

  • Page 86: Rj45 Console Cable

    Raisecom ISCOM2600G (A) Series Product Description 6 Appendix Parameter Description Inner conductor wire gauge 18 AWG Length 1.5 m 6.1.6 RJ45 Console cable Introduction With a Console cable, you can log in to the ISCOM2600G series switch through the Console interface, and then debug and maintain it through a PC.

  • Page 87: Figure 6-12 Wiring Between Db9 Female Connector And Rj45 Console Interface

    Raisecom ISCOM2600G (A) Series Product Description 6 Appendix PIN definition Switch (RJ45) Console (DB9) PIN 6 PIN 7 PIN 8 – PIN 9 Figure 6-12 shows wiring between the DB9 female connector and the RJ45 Console interface on the ISCOM2600G series switch.

  • Page 88: Sfp Modules

    Raisecom ISCOM2600G (A) Series Product Description 6 Appendix 6.2 SFP modules The ISCOM2600G series switch supports the following SFP modules:  100 Mbit/s SFP optical module  100 Mbit/s SFP electrical module  1000 Mbit/s SFP optical module  1000 Mbit/s SFP electrical module ...

  • Page 89: Table 6-14 Parameters Of 1000 Mbit/S Sfp Optical Module

    Raisecom ISCOM2600G (A) Series Product Description 6 Appendix 1000 Mbit/s SFP optical module Table 6-14 lists parameters of the 1000 Mbit/s SFP optical module. Table 6-14 Parameters of 1000 Mbit/s SFP optical module Model Wavelength Minimum Extinction Transmission (nm) (laser...

  • Page 90: Terms

    Raisecom ISCOM2600G (A) Series Product Description 6 Appendix Table 6-16 Parameters of 10 Gbit/s SFP+ optical module Wavelength Maximum Extinction Maximum Model (nm) type optical optical ratio (dB) sensitivity transmission power power distance (dBm) USFP+- -7.3 to - -1.0 -11.1...
  • Page 91 Raisecom ISCOM2600G (A) Series Product Description 6 Appendix Digital Subscriber It is a network device, often located in telephone exchanges, that Line Access connects multiple customer digital subscriber line (DSL) Multiplexer interfaces to a high-speed digital communications channel using (DSLAM) multiplexing techniques.
  • Page 92 Raisecom ISCOM2600G (A) Series Product Description 6 Appendix Multi-mode Fiber In this fiber, multi-mode optical signals are transmitted. (MMF) Protection Ground It is generally a yellow-and-green coaxial cable used for Wire connecting the device to the ground. A network security mechanism, used to solve problems of network delay and congestion.

  • Page 93: Acronyms And Abbreviations

    Raisecom ISCOM2600G (A) Series Product Description 6 Appendix VLAN is a protocol proposed to solve broadcast and security issues for Ethernet. It divides devices in a LAN into different Virtual Local Area segments logically rather than physically, thus implementing Network (VLAN) multiple virtual work groups which are based on Layer 2 isolation and do not affect each other.
  • Page 94 Raisecom ISCOM2600G (A) Series Product Description 6 Appendix ELPS Ethernet Linear Protection Switching Electro Magnetic Compatibility ERPS Ethernet Ring Protection Switching European Telecommunications Standards ETSI European Telecommunications Standards Institute IGMP Internet Group Management Protocol LLDP Link Layer Discovery Protocol Loss of Signal...
  • Page 95 Raisecom ISCOM2600G (A) Series Product Description 6 Appendix Service Level Agreement Strict-Priority SSHv2 Secure Shell v2 Spanning Tree Protocol TACACS+ Terminal Access Controller Access Control System TFTP Trivial File Transfer Protocol UART Universal Asynchronous Receiver/Transmitter Underwriter Laboratories User Network Interface...
