  • Page 1 ISCOM2600 (B) Series Product Description (Rel_03)
  • Page 2 Website: http://www.raisecom.com Tel: 8610-82883305 Fax: 8610-82883056 Email: export@raisecom.com Address: Raisecom Building, No. 11, East Area, No. 10 Block, East Xibeiwang Road, Haidian District, Beijing, P.R.China Postal code: 100094 ----------------------------------------------------------------------------------------------------------------------------------------- Notice Copyright ©2023 Raisecom All rights reserved.
  • Page 3 Raisecom ISCOM2600 (B) Series Product Description Preface Preface Objectives This document describes the ISCOM2600 series switches in terms of product overview, networking applications, system structure, device installation, and technical specifications. The appendix describes cables and SFP modules, and lists terms, acronyms, and abbreviations involved in this document.
  • Page 4 Raisecom ISCOM2600 (B) Series Product Description Preface General conventions Convention Description Times New Roman Normal paragraphs are in Times New Roman. Arial Paragraphs in Warning, Caution, Notes, and Tip are in Arial. Boldface Buttons and navigation paths are in Boldface.

  • Page 5: Table Of Contents

    Raisecom ISCOM2600 (B) Series Product Description Contents Contents 1 Overview ............................1 1.1 Introduction ..............................1 1.2 Features ................................2 1.3 Applications..............................3 1.3.1 Enterprise park network access ....................... 3 1.3.2 Housing estate broadband access ......................4 1.4 Ordering information............................5 1.4.1 Naming convention ..........................
  • Page 6 Raisecom ISCOM2600 (B) Series Product Description Contents 2.7 SFP modules ..............................43 2.7.1 100 Mbit/s SFP optical module ......................43 2.7.2 100 Mbit/s SFP electrical module ......................44 2.7.3 1000 Mbit/s SFP optical module ......................44 2.7.4 1000 Mbit/s SFP electrical module ....................... 45 2.7.5 10 Gbit/s SFP+ optical module ......................
  • Page 7 Raisecom ISCOM2600 (B) Series Product Description Figures Figures Figure 1-1 Enterprise park network access networking ..................4 Figure 1-2 Housing estate broadband access ......................5 Figure 1-3 Naming convention ..........................6 Figure 2-1 Front panel of the ISCOM2600-28X-AC ................... 12 Figure 2-2 Rear panel of the ISCOM2600-28X-AC ....................
  • Page 8 Raisecom ISCOM2600 (B) Series Product Description Figures Figure 2-24 Rear panel of the ISCOM2600-28X-24F-DC/S ................21 Figure 2-25 Front panel of the ISCOM2600-28X-24F-AC_DC ................21 Figure 2-26 Rear panel of the ISCOM2600-28X-24F-AC_DC ................21 Figure 2-27 Front panel of the ISCOM2600-28X-PWR/PWH-AC/D ..............22 Figure 2-28 Rear panel of the ISCOM2600-28X-PWR/PWH-AC/D ..............
  • Page 9 Raisecom ISCOM2600 (B) Series Product Description Figures Figure 4-8 Connecting the ground cable ......................60 Figure 4-9 Connecting the AC power cable ......................60 Figure 4-10 Connecting the DC power cable ....................... 61 Figure 4-11 Connecting the RJ45 Console cable ....................61 Raisecom Proprietary and Confidential Copyright ©...
  • Page 10 Raisecom ISCOM2600 (B) Series Product Description Tables Tables Table 1-1 Features ..............................2 Table 1-2 Naming convention ..........................6 Table 1-3 Ordering information about device ......................7 Table 2-1 Service interfaces ..........................25 Table 2-2 Parameters of the 10 Gbit/s SFP+ optical interface ................27 Table 2-3 Parameters of the 1000 Mbit/s SFP optical interface ................
  • Page 11 Raisecom ISCOM2600 (B) Series Product Description Tables Table 2-24 Parameters of 100 Mbit/s SFP optical modules .................. 44 Table 2-25 Parameters of 100 Mbit/s SFP electrical modules ................44 Table 2-26 Parameters of 1000 Mbit/s SFP optical modules ................44 Table 2-27 Parameters of 1000 Mbit/s SFP electrical modules ................

  • Page 12: Overview

    Applications  Ordering information 1.1 Introduction The Raisecom-developed Ethernet switch ISCOM2600 series switch, which meets the access requirements, is designed for the access layer and can be used as access devices for enterprises. Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.

  • Page 13: Features

    Raisecom ISCOM2600 (B) Series Product Description 1 Overview 1.2 Features Table 1-1 lists features of the ISCOM2600 series switch. Table 1-1 Features Feature Description  Accessing the device (Console/Telnet/SSHv2) Basic features  Managing users   Managing files (BootROM/system files/configuration files) ...

  • Page 14: Applications

    Raisecom ISCOM2600 (B) Series Product Description 1 Overview Feature Description  Security   801.1x  PPPoE+  Port security MAC  Storm control  ARP attack prevention  Dynamic ARP inspection  ND Snooping  DHCP Snooping  DHCP Option ...

  • Page 15: Housing Estate Broadband Access

    Figure 1-1 Enterprise park network access networking 1.3.2 Housing estate broadband access As an access Ethernet switch developed by Raisecom, the ISCOM2600 series switch can work as the core switch for the small-sized network. As shown in Figure 1-2, it is connected upstream to the Layer 3 aggregation switch through the 10GE interface and is connected downstream to the 1000 Mbit/s switch.

  • Page 16: Ordering Information

    Raisecom ISCOM2600 (B) Series Product Description 1 Overview Figure 1-2 Housing estate broadband access 1.4 Ordering information 1.4.1 Naming convention Figure 1-3 shows the naming convention for the ISCOM2600 series switch. Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.

  • Page 17: Figure 1-3 Naming Convention

    Raisecom ISCOM2600 (B) Series Product Description 1 Overview Figure 1-3 Naming convention Table 1-2 describes naming convention for the ISCOM2600 series switch. Table 1-2 Naming convention Domain Indication Value Description Product series ISCOM2 Raisecom ISCOM2600 series device   28: provide 4 uplink interfaces and 24 Number and ...

  • Page 18: Ordering Information About Device

    Raisecom ISCOM2600 (B) Series Product Description 1 Overview Domain Indication Value Description   AC: AC power supply. The input voltage Power supply  range is 100–240 V. type  AC/D  DC: DC power supply. The input voltage ...
  • Page 19 Raisecom ISCOM2600 (B) Series Product Description 1 Overview Model Description  Provide eight 10/100/1000 Mbit/s RJ45 downlink interfaces. ISCOM2600-  Provide four 10 Gbit/s SFP+ uplink interfaces (also supporting 1000 12X-AC Mbit/s SFP).  Provide 1 SNMP interface for out-of-band network management.
  • Page 20 Raisecom ISCOM2600 (B) Series Product Description 1 Overview Model Description  Provide twenty-four 10/100/1000 Mbit/s downlink SFP optical ISCOM2600- interfaces. 28X-24F-DC/S  Provide four 10 Gbit/s SFP+ uplink interfaces (also supporting 1000 Mbit/s SFP).  Provide 1 SNMP interface for out-of-band network management.
  • Page 21 Raisecom ISCOM2600 (B) Series Product Description 1 Overview Model Description  Provide twenty-four 10/100/1000 Mbit/s RJ45 downlink optical ISCOM2600- interfaces. 28X-PWR-  Provide four 10 Gbit/s SFP+ uplink interfaces (also supporting 1000 AC_DC Mbit/s SFP).  Provide 1 SNMP interface for out-of-band network management.
  • Page 22 Raisecom ISCOM2600 (B) Series Product Description 1 Overview Model Description  Provide twenty-four 10/100/1000 Mbit/s RJ45 downlink optical ISCOM2600- interfaces. 28X-PWH-  Provide four 10 Gbit/s SFP+ uplink interfaces (also supporting 1000 AC_DC Mbit/s SFP).  Provide 1 SNMP interface for out-of-band network management.

  • Page 23: System Structure

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure System structure This chapter describes system structure of the ISCOM2600 series switch, including the following sections:  Panels  Interfaces  LEDs  Button  Power interfaces  Cables  SFP modules 2.1 Panels...

  • Page 24: Iscom2600-28G

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure USB, PWR, SYS, SNMP, MST, and STK LEDs USB interface Figure 2-2 shows the rear panel of the ISCOM2600-28X-AC. Figure 2-2 Rear panel of the ISCOM2600-28X-AC ISCOM2600-28X-DC Figure 2-3 shows the front panel of the ISCOM2600-28X-DC.

  • Page 25: Figure 2-5 Front Panel Of The Iscom2600-28G-Ac

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Figure 2-5 Front panel of the ISCOM2600-28G-AC Ground terminal Power interface Service interfaces (1–28) LEDs Service downlink interfaces (1–24) Service uplink interfaces (25–28) SNMP interface and Console interface USB, PWR, SYS, SNMP, MST, and STK LEDs USB interface Figure 2-6 shows the rear panel of the ISCOM2600-28G-AC.

  • Page 26: Iscom2600-12X

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Figure 2-8 Rear panel of the ISCOM2600-28G-DC 2.1.3 ISCOM2600-12X ISCOM2600-12X-AC Figure 2-9 shows the front panel of the ISCOM2600-12X-AC. Figure 2-9 Front panel of the ISCOM2600-12X-AC Power interface Service interfaces (1–12) LEDs Service downlink interfaces (1–8)

  • Page 27: Iscom2600-12G

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Figure 2-11 Front panel of the ISCOM2600-12X-DC Power interface Service interfaces (1–12) LEDs Service downlink interfaces (1–8) Service uplink interfaces (9–12) SNMP interface, Console interface, and USB USB, MST, STK, SNMP, SYS, and PWR LEDs...

  • Page 28: Figure 2-13 Front Panel Of The Iscom2600-12G-Ac

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Figure 2-13 Front panel of the ISCOM2600-12G-AC Power interface Service interfaces (1–12) LEDs Service downlink interfaces (1–8) Service uplink interfaces (9–12) SNMP interface, Console interface, and USB USB, MST, STK, SNMP, SYS, and PWR LEDs...

  • Page 29: Iscom2600-28X-24F

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Power interface Service interfaces (1–12) LEDs Service downlink interfaces (1–8) Service uplink interfaces (9–12) SNMP interface, Console interface, and USB USB, MST, STK, SNMP, SYS, and PWR LEDs interface Ground terminal Figure 2-16 shows the rear panel of the ISCOM2600-12G-DC.

  • Page 30: Figure 2-19 Front Panel Of The Iscom2600-28X-24F-Dc/D

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Ground terminal Power interface 2 Switch for power interface 1 ISCOM2600-28X-24F-DC/D Figure 2-19 shows the front panel of the ISCOM2600-28X-24F-DC/D. Figure 2-19 Front panel of the ISCOM2600-28X-24F-DC/D Service downlink interfaces (1–24) and LEDs Service uplink interfaces (25–28) and LEDs...

  • Page 31: Figure 2-21 Front Panel Of The Iscom2600-28X-24F-Ac/S

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Figure 2-21 Front panel of the ISCOM2600-28X-24F-AC/S Service downlink interfaces (1–24) and LEDs Service uplink interfaces (25–28) and LEDs SNMP interface, Console interface, and USB SYS, PWR1, PWR2, MST, STK, USB, and...

  • Page 32: Figure 2-24 Rear Panel Of The Iscom2600-28X-24F-Dc/S

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Figure 2-24 Rear panel of the ISCOM2600-28X-24F-DC/S Power interface 1 Switch for power interface Ground terminal ISCOM2600-28X-24F-AC_DC Figure 2-25 shows the front panel of the ISCOM2600-28X-24F-AC_DC. Figure 2-25 Front panel of the ISCOM2600-28X-24F-AC_DC Service downlink interfaces (1–24) and LEDs...

  • Page 33: Iscom2600-28X-Pwr/Iscom2600-28X-Pwh

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure 2.1.6 ISCOM2600-28X-PWR/ISCOM2600-28X-PWH ISCOM2600-28X-PWR/PWH-AC/D Figure 2-27 shows the front panel of the ISCOM2600-28X-PWR/PWH-AC/D. Figure 2-27 Front panel of the ISCOM2600-28X-PWR/PWH-AC/D Service downlink interfaces (1–24) Service uplink interfaces (25–28) SNMP interface, Console interface, and USB Service downlink interfaces (1–24) LEDs...

  • Page 34: Figure 2-29 Front Panel Of The Iscom2600-28X-Pwr/Pwh-Dc/D

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Figure 2-29 Front panel of the ISCOM2600-28X-PWR/PWH-DC/D Service downlink interfaces (1–24) Service uplink interfaces (25–28) SNMP interface, Console interface, and USB Service downlink interfaces (1–24) LEDs interface POE, SYS, PWR1, PWR2, MST, STK, USB, and Service uplink interfaces (25–28) LEDs...

  • Page 35: Figure 2-32 Rear Panel Of The Iscom2600-28X-Pwr/Pwh-Ac/S

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure SNMP interface, Console interface, and USB Service downlink interfaces (1–24) LEDs interface POE, SYS, PWR1, PWR2, MST, STK, USB, and Service uplink interfaces (25–28) LEDs SNMP LEDs PoE mode switching button Figure 2-32 shows the rear panel of the ISCOM2600-28X-PWR/PWH-AC/S.

  • Page 36: Interfaces

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Figure 2-34 Rear panel of the ISCOM2600-28X-PWR/PWH-AC_DC Ground terminal for power interface 1 Power interface 1 Switch for power interface 1 Power interface 2 Switch for power interface 2 2.2 Interfaces The ISCOM2600 series switch provides external interfaces, such as service interfaces, management interfaces, and power interfaces.
  • Page 37 Raisecom ISCOM2600 (B) Series Product Description 2 System structure Interface Quantity Description ISCOM2600- Support the following optical modules:  The 10 Gbit/s SFP+ optical interface supports the following SFP+ optical module: 10GBASE-X.  The 1000 Mbit/s SFP optical interface supports the following SFP optical module: 1000BASE-X.

  • Page 38: Table 2-2 Parameters Of The 10 Gbit/S Sfp+ Optical Interface

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Interface Quantity Description ISCOM2600- 10/100/1000BASE-T auto-negotiation electrical interface ISCOM2600- 10/100/1000BASE-T auto-negotiation electrical interface ISCOM2600- 10/100/1000BASE-T auto-negotiation 28X-24F electrical interface ISCOM2600- 10/100/1000BASE-T auto-negotiation 28X-PWR electrical interface ISCOM2600- 10/100/1000BASE-T auto-negotiation 28X-PWH electrical interface 10 Gbit/s SFP+ optical interface Table 2-2 lists parameters of the 10 Gbit/s SFP+ optical interface.

  • Page 39: Management Interfaces

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Table 2-4 Parameters of the 10/100/1000 Mbit/s Ethernet electrical interface Parameter Description Connector type RJ45  10/100/1000 Mbit/s auto-negotiation Working mode  Full/Half duplex auto-negotiation  When the interface is working at 10/100 Mbit/s, we Cable specifications recommend using the Cat 5 UTP cable.

  • Page 40: Leds

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Table 2-7 Parameters of the SNMP interface Parameter Description Connector type RJ45 Transmission rate 10/100/1000BASE-T auto-negotiation Wiring Support adaption to the straight-through cable and crossover cable in host mode. Standard IEEE 802.3 2.3 LEDs...

  • Page 41: Button

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Status Description Green USB interface working LED  Green: USB deployment is successful. The USB interface is connected properly.  Fast blinking: the USB interface is transmitting data.  Slow blinking: USB deployment fails.

  • Page 42: Power Interfaces

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Table 2-9 Mode button POE LED Button Usage Description status Mode Press it to Green If the PoE LED is green after the Mode button is switch the pressed, it indicates that the service downlink displaying interface (1–24) LED is the PoE status LED.

  • Page 43: Ac Power Interface

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Table 2-10 DC power interface Power interface Type Print Usage – DC power interface Fence terminal -48V power input terminal GND power input terminal Parameters Table 2-11 lists parameters of the DC power interface.

  • Page 44: Cables

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Parameter Description Voltage range 100–240 VAC 2.6 Cables The following cables are used when connecting the ISCOM2600 series switch:  Cables  Ethernet cable  Ground cable  DC power cable ...

  • Page 45: Ethernet Cable

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Appearance Figure 2-38 shows the LC/PC fiber connector. Figure 2-38 LC/PC fiber connector When connecting or removing the LC/PC optical connector, align the connector with the optical interface, and do not rotate the fiber. Operate the fiber as below: ...

  • Page 46: Figure 2-39 Ethernet Cable

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Appearance Figure 2-39 shows the Ethernet cable. Figure 2-39 Ethernet cable Technical specifications The Ethernet cables are divided into two types:  Straight-through cable: used to connect devices of different type, such as between a PC and a switch, or between a switch and a router ...

  • Page 47: Figure 2-40 Wiring Of 10/100/1000 Mbit/S Straight-Through Cable

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Figure 2-40 Wiring of 10/100/1000 Mbit/s straight-through cable Figure 2-41 shows wiring of the 100 Mbit/s crossover cable. Figure 2-41 Wiring of the 100 Mbit/s crossover cable Figure 2-42 shows wiring of 1000 Mbit/s crossover cable.

  • Page 48: Ground Cable

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Figure 2-42 Wiring of the 1000 Mbit/s crossover cable Technical specifications Table 2-16 lists technical specifications of the Ethernet cable. Table 2-16 Technical specifications of the Ethernet cable Parameter Description Name...

  • Page 49: Figure 2-43 Ground Cable

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure flame-retardant conducting wire. Figure 2-43 and Figure 2-44 show the ground cable and OT terminal. Figure 2-43 Ground cable 1 Conducting wire Stripped end (connected to the OT terminal) 3 Insulating sheath...

  • Page 50: Dc Power Cable

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure The ground cable cannot be longer than 30 m and should be as short as possible; otherwise, a ground bar should be used. 2.6.4 DC power cable Introduction The DC power cable transmits -48 VDC power to the power interface on the ISCOM2600 series switch, and supplies power for the whole device.

  • Page 51: Ac Power Cable

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure 2.6.5 AC power cable Introduction The AC power cable transmits 220 VAC power to the power interface on the ISCOM2600 series switch, and supplies power for the whole device. The AC power cables used by the ISCOM2600 series switch vary with countries or regions, as lists in Table 2-19.

  • Page 52: Rj45 Console Cable

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Parameter Description Inner Blue (N), brown (L), and yellow/green stripe (E) Connector 1 IEC60320-C13 connector Connector 2 European 3-pin plug Inner conductor cross- 3× 0.75 mm sectional area Length 1.5 m Table 2-21 lists technical specifications of the American AC power cable.

  • Page 53: Figure 2-48 Rj45 Console Cable

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Figure 2-48 RJ45 Console cable Wiring Table 2-22 lists wiring of the RJ45 Console interface. Table 2-22 Wiring of the RJ45 Console interface PIN definition Switch (RJ45) Console (DB9) PIN 1...

  • Page 54: Sfp Modules

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Figure 2-49 Wiring between the DB9 female connector and RJ45 Console interface Technical specifications Table 2-23 lists technical specifications of the RJ45 Console cable. Table 2-23 Technical specifications of the RJ45 Console cable...

  • Page 55: 100 Mbit/S Sfp Electrical Module

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Table 2-24 Parameters of 100 Mbit/s SFP optical modules Wavelength Receive Minimum Extinctio Maximum Model (nm) (laser r type optical overload n ratio sensitivit transmissi type) power point (dB) y (dBm)

  • Page 56: 1000 Mbit/S Sfp Electrical Module

    Raisecom ISCOM2600 (B) Series Product Description 2 System structure Model Wavelength Receive Minimum Extinctio Maximum (nm) (laser r type optical overload n ratio sensitivit transmissi type) power point (dB) y (dBm) on distance (dBm) (dBm) (km) USFP- 1550(DFB) 0 to 5...

  • Page 57: Technical Specifications

    Raisecom ISCOM2600 (B) Series Product Description 3 Technical specifications Technical specifications This chapter describes overall parameters, system parameters, card parameters, and performance specifications, including the following sections:  Overall parameters  Compliant protocols and standards  Laser safety class ...
  • Page 58 Raisecom ISCOM2600 (B) Series Product Description 3 Technical specifications Parameter Description  ISCOM2600-12G: < 15  ISCOM2600-28X-24F: < 55  ISCOM2600-28X-PWR: – ISCOM2600-28X-PWR-DC/D: the overall power consumption is 750 W; wherein, the maximum power for PoE is 720 W. –...

  • Page 59: Compliant Protocols And Standards

    Raisecom ISCOM2600 (B) Series Product Description 3 Technical specifications Parameter Description  ISCOM2600-28X-PWR-AC/D: 5.2  ISCOM2600-28X-PWR-DC/D: 4.6  ISCOM2600-28X-PWR-AC/S: 4.7  ISCOM2600-28X-PWR-AC_DC: 5.0  ISCOM2600-28X-PWH-AC/D: 5.2  ISCOM2600-28X-PWH-DC/D: 4.6  ISCOM2600-28X-PWH-AC/S: 4.7  ISCOM2600-28X-PWH-AC_DC: 5.0 Operating temperature (altitude 0– 0–55° C...

  • Page 60: Laser Safety Class

    Raisecom ISCOM2600 (B) Series Product Description 3 Technical specifications  IEEE 802.3-2005 Part 3: Carrier sense multiple access with collision detection (CSMA/CD) access method and physical layer specifications  IEEE 802.1ag: Virtual Bridged Local Area Networks Amendment 5: Connectivity Fault Management ...

  • Page 61: Reliability Specifications

    Raisecom ISCOM2600 (B) Series Product Description 3 Technical specifications The laser inside fiber may hurt your eyes. Do not stare into the optical interface directly during installation and maintenance. 3.4 Reliability specifications Table 3-2 lists reliability specifications of the ISCOM2600 series switch.

  • Page 62: Environmental Requirements

    Raisecom ISCOM2600 (B) Series Product Description 3 Technical specifications 3.7 Environmental requirements The ISCOM2600 series switch complies with the following environmental requirements:  GF 014-1995: telecommunication equipment room conditions  NEBS GR-63-CORE: Network Equipment-Building System (NEBS) Requirements: Physical Protection ...

  • Page 63: Transport Environment

    Raisecom ISCOM2600 (B) Series Product Description 3 Technical specifications  Rodent animals, such as rats 3.7.2 Transport environment Atmosphere environment Table 3-4 lists atmosphere requirements for the ISCOM2600 series switch during transport. Table 3-4 Atmosphere requirements during transport Parameter Description Air pressure (kPa) 86–106...
  • Page 64 Raisecom ISCOM2600 (B) Series Product Description 3 Technical specifications Parameter Description Relative humidity 10%–90% (non-condensing) ≤ 0.5 Temperature change rate (° C/min) ≤ 700 Solar radiation (W/s² ) ≤ 600 Heat radiation (W/s² ) ≤ 5 Wind speed (m/s) Biotic environment Keep the ISCOM2600 series switch away from: ...

  • Page 65: Device Installation

    Raisecom ISCOM2600 (B) Series Product Description 4 Device installation Device installation This chapter describes how to install the ISCOM2600 series switch, including the following sections:  Installing hardware  Installing software 4.1 Installing hardware The ISCOM2600 series switch adopts a 1U cartridge structure. It can be easily installed in the following scenarios of a telecom equipment room: ...

  • Page 66: Table 4-2 Power Supply Requirements On Operation

    Raisecom ISCOM2600 (B) Series Product Description 4 Device installation Power supply conditions Table 4-2 lists power supply requirements on the operation of the ISCOM2600 series switch. Table 4-2 Power supply requirements on operation Parameter Description  AC power: the rated voltage is 220 VAC, and the voltage Power supply range is 100–240 VAC.

  • Page 67: Installing Device

    Raisecom ISCOM2600 (B) Series Product Description 4 Device installation 4.1.2 Installing device Rack installation The installation modes of the SCOM2600-28X, ISCOM2600-28X-24F, and ISCOM2600-28X-PWR/PWH are identical. The ISCOM2600-12X has a small chassis, so it does not need to be installed with brackets. The following installation takes the ISCOM2600-28X for example.

  • Page 68: Figure 4-2 Installing Cage Nuts

    Raisecom ISCOM2600 (B) Series Product Description 4 Device installation Figure 4-2 Installing cage nuts Step 4 Install guide rails in the rack, as shown in Figure 4-3. Figure 4-3 Installing guide rails Step 5 Use screws to fix two customized brackets to guide rail, and install the ISCOM2600 series switch horizontally in the rack, as shown in Figure 4-4.

  • Page 69: Connecting Cables

    Raisecom ISCOM2600 (B) Series Product Description 4 Device installation Figure 4-4 Installing the device horizontally in the rack Do not lay heavy objects or coverings on the ISCOM2600 series switch. 4.1.3 Connecting cables Connecting fiber There is invisible laser which harms eyes inside the ISCOM2600 series switch. Do not stare into the optical interface, fiber connector, or breakage of fiber directly.

  • Page 70: Figure 4-6 Connecting The Fiber

    Raisecom ISCOM2600 (B) Series Product Description 4 Device installation Figure 4-6 Connecting the fiber  Figure 4-6 takes the 1000 Mbit/s SFP optical module for example. The connection of the 10 Gbit/s SFP+ optical module is identical.  When the optical interface is idle, cover it with a dustproof cap to prevent dust and dirt which may make the ISCOM2600 series switch work improperly.

  • Page 71: Figure 4-8 Connecting The Ground Cable

    Raisecom ISCOM2600 (B) Series Product Description 4 Device installation Step 3 Reinstall the screw to the ground terminal, and tighten the screws clockwise, as shown in Figure 4-8. Figure 4-8 Connecting the ground cable Connecting AC power cable Connect the AC power cable as below: Step 1 Ensure that the ISCOM2600 series switch is well grounded.

  • Page 72: Installing Software

    Raisecom ISCOM2600 (B) Series Product Description 4 Device installation Figure 4-10 Connecting the DC power cable Step 4 Connect the other end of the DC power cable to the power sourcing equipment in the equipment room. Connecting RJ45 Console cable...

  • Page 73: Appendix

    Raisecom ISCOM2600 (B) Series Product Description 5 Appendix Appendix The appendix lists cables, SFP modules, terms, acronyms, and abbreviations, including the following sections:  Terms  Acronyms and abbreviations 5.1 Terms A series of ordered rules composed of permit | deny sentences.
  • Page 74 Raisecom ISCOM2600 (B) Series Product Description 5 Appendix A security feature that can be used to verify the ARP data Dynamic ARP packets in the network. With DAI, the administrator can Inspection (DAI) intercept, record, and discard ARP packets with invalid MAC address/IP address to prevent common ARP attacks.
  • Page 75 Raisecom ISCOM2600 (B) Series Product Description 5 Appendix Link-state tracking provides an interface linkage scheme, extending the range of link backup. Through monitoring uplinks and synchronizing downlinks, faults of the upstream device can Link-state tracking be transferred quickly to the downstream device, and primary/backup switching is triggered.

  • Page 76: Acronyms And Abbreviations

    Raisecom ISCOM2600 (B) Series Product Description 5 Appendix Single-mode Fiber In this fiber, single-mode optical signals are transmitted. (SMF) VLAN is a protocol proposed to solve broadcast and security issues for Ethernet. It divides devices in a LAN into different...
  • Page 77 Raisecom ISCOM2600 (B) Series Product Description 5 Appendix Ethernet Demarcation Device Ethernet in the First Mile ELPS Ethernet Linear Protection Switching Electro Magnetic Compatibility ERPS Ethernet Ring Protection Switching European Telecommunications Standards ETSI European Telecommunications Standards Institute IGMP Internet Group Management Protocol...
  • Page 78 Raisecom ISCOM2600 (B) Series Product Description 5 Appendix Relative Humidity RMON Remote Network Monitoring Service Level Agreement Strict-Priority SSHv2 Secure Shell v2 Spanning Tree Protocol TACACS+ Terminal Access Controller Access Control System TFTP Trivial File Transfer Protocol UART Universal Asynchronous Receiver/Transmitter...
  • Page 79 Address Raisecom Building, No. 11, East Area, No. 10 Block, East Xibeiwang Road, Haidian District, Beijing, P.R.China Postal code: 100094 Tel: +86-10-82883305 Fax: 8610-82883056 http://www.raisecom.com Email: export@raisecom.com...

This manual is also suitable for:

Iscom2600-28x-acIscom2600-28x-dcIscom2600-28g-acIscom2600-28g-dcIscom2600-12x-acIscom2600-12x-dc ... Show all
