Terminal Identification - Altronix WPTV248UL Installation Manual

CAUTION: Determine the maximum operating voltage of the equipment being powered before adjusting
the output voltage.
8. Connect devices to terminals marked [1P - 1N through 8P - 8N] on PD8/PD8CB board (Figs. 2-4, pgs. 5-7),
carefully observing polarity.
9. Slide switch on PD board to ON position for models WPTV248UL and WPTV248ULCB (Fig. 2, pg. 5).
Turn main switch on all other models to the ON (RESET) position (Figs. 3-4, pgs. 6-7).
10. Green LED will illuminate when unit is powered.
11. Upon completion of wiring, secure enclosure door with the cam lock (supplied).
Caution: Equipment to be installed / serviced by authorized / trained personnel only.
Shut branch circuit power before installing / servicing equipment.
WARNING: This installation should be made by qualified service personnel. Unit should be installed in
accordance with the National Electrical Codes and all local codes. For continued protection against risk
of fire replace all fuses only with the same type and rating
(3.5 amp/250VAC).
PD8 - Power Distribution Module
1P - 8P
1N - 8N

Terminal Identification:

AC output.
AC output.
- 3 - - 3 -
