Altronix WPTV248UL Installation Manual page 5

Fig. 2
WPTV248UL • WPTV248ULCB
Fig. 2A
Used on PTC Models
(example: WPTV248ULCB)
F 1 F 2 F 3 F 4 F 5 F 6
P
F U S E D P O W E R O U T P U T S
N
C O M M O N P O W E R O U T P U T S
Power Limited
Class 2
Terminal Blocks for Fig. 2
24VAC fused or PTC
protected outputs
1 through 8.
F 7 F 8
PD8
D1
LED
R1
INPUT
Input:
24VAC
operation.
1 2 3 4 5 6 7 8
PD8
P
F U S E D P O W E R O U T P U T S
N
C O M M O N P O W E R O U T P U T S
non-power
limited
XFMR
- 5 -
D1
LED
R1
INPUT
non-power
limited
Black
Black Lead
Lead
115VAC
Input
50/60 Hz.
White
Lead
Green
Lead
(Ground)
