XVME-500/590 Manual
February, 1988
Table C-4. P2's - JKl Compatibility Pin-out (Cont'd)
Flat Cable
Conductor
46
47
48
49
50
Jumper
JlA
JlB
J2A
J2B
J3A
J3B
J4A
J4B
J5A
J5B
J6
J7
J8
J9
Jl0
Jll
J12
J13
J14
J15
J16
J18
J19
J20
J17
J21A
J21B
J21C
J21D
J22A
J22B
J22C
J22D
J23
Single-Ended
Configuration
CH. 31
CH. 23
ANALOG GND
POWER GND/PD GND
EXT TRIGGER
Table C-5. XVME-500/590 Jumper List
Description
Analog-to-binary conversion with J4A
Analog-to-two's complement conversion with J4B
Allows 12-bit resolution in ADC conversions
Allows 8-bit resolution in ADC conversions
Voltage range selector to ADC; 0-l0V, +5V
Voltage range selector to ADC; +lOV
Analog-to-binary conversion with J1A
Analog-to-two's complement conversion with J1B
Unipolar voltage range selector
Bipolar voltage range selector
Fixed gain selector (x1000)
Resistor programmable gain selector
Fixed gain selector (x100)
Fixed gain selector (x10)
A3 interrupt level selector
A2 interrupt level selector
Al interrupt level selector
IN = supervisory only; OUT = supervisory
Programmable gain range selector; Range 2 (4, 8, 20, 40)
Programmable gain range selector; Range 1 (1, 2, 5, 10)
Programmable gain range selector; Range 3 (10, 20, 50, 100)
Programmable gain range selector (accompanies J14)
Programmable gain range selector (accompanies J15)
Programmable gain range selector (accompanies J16)
External trigger selector (remove J21A-D;do not use with PDI)
Configures module for SE operation;accompanies J25 &J21C
Configures module for DI operation
Configures module for SE operation with J21A
Configures module for PDI operation with J21A & J25
Determines settling time 24uSec for fixed gain x100
Determines settling time 10uSec for programmable gain amp
Determines settling time 80uSec for fixed gain xl-100
Determines settling time 16uSec (not used)
Ground allows auto drift control by software input calib.
Differential
Configuration
CH. 15 HI
CH. 15 LO
ANALOG GND
POWER GND/PD GND C25
EXT TRIGGER
c-7
P2
Connector
A23
C24
A24
A25
or non-privileged
or D
& J25
