XVME-500 and XVME-590 Analog Input Module Specifications
. Characteristic
Number of Channels
Single-ended
Differential
Supply Voltage
Supply Current
Maximum
Typical
Accuracy
Resolution
Linearity
Differential
Monotonicity
System Accuracy
Gain = 1
Gain = 10
Gain = 100
System Accuracy Temperature Drift
Gain = 1
Gain = 10
Gain = 1 0 0
Common Mode Rejection Ratio
Analog-to-Digital Input (Gain = 1)
Full Scale Voltage Ranges
Unipolar
Bipolar
Linearity
Table 1-2
1-7
Specification
16 (32 optional)
8 (16 optional)
+5 VDC, ~5%
1.90 A
1.60 A
12 bits
+0.5 LSB
50.5 LSB
Guaranteed*
+0.0l% FSR, max.
+0.l% FSR, max.
+ 0 1% FSR, max.
40 ppm/Degree
75 ppm/Degree
110 ppm/Degree
60db min.
0-10V
C,
max.
C, max.
C, max.
