XVME-500/590 Manual
February, 1988
3.1 INTRODUCTION
This chapter provides information required to program the XVME-500/590 Analog
Input Module for analog-to-digital signal conversions.
information is as follows:
Presentation of the module address map with programming locations
l
Discussion of base addressing and how the conversion registers are
l
accessed
A/D conversion modes and principals
3.2 BASE ADDRESSING
The XVME-500/590 Analog Input Module is designed to be addressed within the
VMEbus- defined 64K Short I/O Address Space.
system, it will occupy a IK byte block of the Short I/O Address Space.
address decoding scheme for the XVME I/O modules positions the starting address
for each board on a 1K boundary.
boundaries) for the XVME-500/590 within the Short I/O Address Space. (Refer to
Section 2.5.1 for the list of base addresses and their corresponding list of jumper
c o n f i g u r a t i o n s . )
The logical registers utilized for the conversion data on the XVME-500/590 are
given specific addresses within the 1K of block-address space occupied by the
module. These addresses are offset from the module base address.
shows a representative memory map for the XVME-500/590 module.
Chapter 3
PROGRAMMING
When the module is installed in a
Thus, there are 64 possible base addresses (1K
3-l
The presentation of the
The base
Figure 3-1
