Xycom XVME 590 Manual page 83

XVME-500/590 Manual
February, 1988
Flat Cable
Conductor
39
40
41
42
43
44
45
46
47
48
49
50
* Those channels marked by (*) are only available after an XVME-910 channel
expansion kit is installed.
Table C-3. Input Connector JKl (cont'd)
Single-Ended
Configuration
ANALOG GND
CH. 29"
CH. 21"
ANALOG GND
CH. 22*
CH. 30*
ANALOG GND
CH. 31*
CH. 23*
ANALOG GND
POWER GND/PD GND
EXT TRIGGER
C-5
Differential
Configuration
ANALOG GND
CH. 13 HI*
CH. 13 LO*
ANALOG GND
CH. 14 LO*
CH. 14 HI*
ANALOG GND
CH. 15 HI*
CH. 15 LO*
ANALOG GND
POWER GND/PD GND
EXT TRIGGER
