* XVME-500/590 Manual
February, 1988
J17
J21A,J21B,J21C,J21D,
J25
J22A,J22B,J22C,
J22D
J23,J24
J32 (XVME-590 Only)
Table C-l. XVME-500/590 Jumpers (Cont'd)
This jumper is installed to provide ground reference
for external trigger (521 must be removed if this
option is used; See Section 2.6.4.5)
These jumpers are used together to determine if the
inputs will be configured as either 8 differential,
16 single-ended or 16 pseudo-differential input
channels (Section 2.6.2)
Each jumper is used to determine settling times for
the appropriate module amplifier (Section 3.4.1)
These two jumpers are provided to allow grounding
of an input channel in either the single-ended or the
differential input mode of operation for purposes of
calibration (See Section 2.6.5)
Connects Analog to Digital GND. J32 is
foil and can be cut if the user desires.
