XVME-500/590 Manual
February, 1988
Table 2-13. P2's - JKI Compatibility Pin-out (Cont'd)
Flat Cable
Conductor
46
47
48
49
50
2.8 JUMPER LIST
The following table summarizes all the XVME-500/590 jumpers and their functions.
Jumper
Analog-to-binary conversion with J4A
JlA
JlB Analog-to-two's complement conversion with J4B
Allows 12-bit resolution in ADC conversions
J2A
Allows 8-bit resolution in ADC conversions
J2B
Voltage range selector to ADC; 0-l0V, +5V
J3A
J3B Voltage range selector to ADC; +l0V
J4A Analog-to-binary conversion with J1A
J4B Analog-to-two's complement conversion with J1B
J5A Unipolar voltage range selector
J5B Bipolar voltage range selector
J6 Fixed gain selector (x1000)
J7 Resistor programmable gain selector
J8 Fixed gain selector (x100)
J9 Fixed gain selector (x10)
A3 interrupt level selector
Jl0
Jll A2 interrupt level selector
J12 Al interrupt level selector
J13 IN = supervisory only; OUT = supervisory
J14 Programmable gain range selector; Range 2 (4, 8, 20, 40)
J15 Programmable gain range selector; Range 1 (1, 2, 5, 10)
J16 Programmable gain range selector; Range 3 (10, 20, 50, 100)
J18 Programmable gain range selector (accompanies J14)
J19 Programmable gain range selector (accompanies J15)
J20 Programmable gain range selector (accompanies J16)
J17 External trigger selector (remove J21A-D;do not use with PDI)
J21A Configures module for SE operation;accompanies J25 & J21C
J2lB Configures module for DI operation
J21C Configures module for SE operation with J21A & J25
J21D . Configures module for PDI operation with J21A & J25
Single-Ended
Configuration
CH. 31
CH. 23
ANALOG GND
POWER GND/PD GND
EXT TRIGGER
Table 2-14. XVME-500/590 Jumper List
Description
Differential
Configuration
CH. 15 HI
CH. 15 LO
ANALOG GND
POWER GND/PD GN
EXT TRIGGER
2-24
onnector
or non-privileged
or D
P 2
A23
C24
A 2 4
C25
A25
