XVME-500/590 Manual
February, 1988
Appendices
terms of the XVME-9 10 channel expansion kit; backplane signal/pin
descriptions; block diagram, assembly illustration and schematics; and a quick
reference
section.
1.3 MODULE OPERATIONAL DESCRIPTION
Figure l-1 shows the operational block diagram of the XVME-500 and Figure 1-2
shows the operational block diagram of the XVME-590 Analog Input Module.
- The Appendices are designed to provide additional information in
1-2
