XVME-500/590 Manual
February, 1988
Characteristic
Programmable Gain (versions 2 & 3)
Range 1
Range 2
Range 3
Fixed Gain (version 3)
Resistor programmable
Maximum Input Voltage
Power on
Power off
Input Impedance
w 1OM ohm resistor
w/o 1OM ohm resistor
Bias Current
Input Capacitance
Operating Common Mode Voltage
Speed
Conversion Time
versions 1 & 2
version 3
Throughput
version 1
version 2
version 3
Settling Time
version 1
versions 2 & 3
External
Table 1-2 (cont'd)
Frequency
Trigger-to-Sample
xl, x10, x100, xl000
12-bit
25uSec
10uSec
20KHz
28.5KHz
50KHz
25uSec
10uSec
10 or 20uSec
1-8
Specification
1, 2, 5, or 10
4, 8, 20 or 40
10, 20, 50, or 100
1OM ohm min.
1OOM ohm min.
+ 1 OOnA max.
1 OOpf max.
14v
8-bit
17uSec
6.8uSec
23.8KHz
37KHz
59.5KHz
25uSec
10uSec
10, 25uSec
