XVME-500/590 Manual
February, 1988
2.10
MODULE
XYCOM XVME modules are designed to comply with all physical and electrical
VMEbus backplane
high VMEbus module. As such, it only requires the Pl backplane. The XVME-590
Analog Input Module may use the P2 of the VMEbus backplane.
Never attempt to install or remove any boards before turning
off the power to the bus, and all related external power
supplies.
Prior to installing a module, you should determine and verify
all relevant jumper configurations, and all connections to
external devices or power supplies.
, configuration against the diagrams and lists in this manual.)
To install a board in the cardcage, perform the following steps:
1) Make sure the cardcage slot (which will hold the module) is clear and
accessible.
2) Center the board on the plastic guides in the slot (so the handle on the
front panel is towards the bottom of the cardcage).
3) Push the card slowly toward the rear of the chassis, until the connectors
engage (the card should slide freely in the plastic guides).
4) Apply straightforward pressure to the handle on the panel front, until the
connector is fully engaged and properly seated.
INSTALLATION
specifications. The XVME-500 Analog Input Module is a single-
C A U T I O N
(Please check the jumper
2-26
