XVME-500/590 Manual
February, 1988
VMEbus OPTIONS
Jumpers
Jl0,Jll,J12
J26,J27,J28,J29
J30,J31
.
J13
Analog-to-Digital Conversion OPTIONS
Jumpers
JlA,JlB,J4A,J4B
J2A
J2B
J6,J8,J9
J7
J14,J15,J16,J18,
J19,520
Appendix C
QUICK REFERENCE GUIDE
Table C-l. XVME-500/590 Jumpers
Use
Interrupt level select for any interrupts generated by
the module (See Section 2.5.3)
Module base address select jumpers
Section 2.5.1)
This jumper allows module to respond to supervisory
access only (when installed) or to both supervisory
and non-privileged access (when removed; See 2.5.2)
Use
These jumpers provide the option of converting
analog inputs to either a two's complement, straight
binary or offset binary format (See Section 2.6.1)
Selects 12-bit conversions for analog-to-digital
converter (See Section 2.6.4.4)
Selects 8-bit
converter (See Section 2.6.4.4)
These jumpers are used to configure inputs for either
bipolar or unipolar input voltages and ranges (See
Section 2.6.3)
Selects fixed-gain amplification factor on version 1
ONLY (Section 2.6.4.2)
Used only for modifying version 1 for resistor
programmable gain (Section 2.6.4.3)
This jumper configuration controls gain ranges for
programmable gain amplifier (versions 2 & 3) (See
Section 2.6.4.1)
C-l
conversions for analog-to-digital
(refer to
