- Page 1 INSTALLATION INSTRUCTIONS FOR PART 99-3528 APPLICATIONS 2004-2006 Pontiac GTO 99-3528 KIT FEATURES • DIN Head Unit Provisions with Oversized Pocket KIT COMPONENTS A) Radio Housing TOOLS REQUIRED: 86-3528 Radio Removal Keys • Flat Blade Screwdriver • Phillips Screwdriver...
- Page 2 99-3528 2004-2006 PONTIAC GTO Disconnect the negative battery ter- minal to prevent an accidental short circuit. Using the radio removal keys, pull the factory head unit from the dash and disconnect the wiring. (Figure A) Unsnap and remove the trim panel at...
- Page 3 99-3528 2004-2006 PONTIAC GTO Remove (2) Phillips screws exposed at the bottom of the center panel surrounding radio and remove panel. (Figure E) Unclip and remove trim panel sur- rounding radio and A/C controls. Remove (3) Phillips screws holding "cage" in radio opening. (Figure F) Pull down on the "cage"...
- Page 4 99-3528 Slide the DIN cage into the Radio Housing and secure by bending the metal locking tabs down. (Figure A) Slide the aftermarket head unit into the cage and secure. (Figure B)
- Page 5 99-3528 Strip wire ends back 1/2" Twist ends together Solder Tape Locate the factory wiring harness in the dash. Metra recommends using the proper mating adapter and making the connections as shown. (Isolate and individually tape off the ends of any unused...
