dCS Vivaldi Upsampler Plus User Manual
F
P
RONT
ANEL
A
B
Remote Control Receiver
Aim the remote control handset towards the receiver (A) for best sensitivity.
Display
In normal use, the selected input appears at the top left corner of the display (B). To the right of this,
the input word length / sample rate and output sample rate appear. The sample rates are replaced by
No Input
when a recognisable data stream is not detected.
The Filter, Sync Mode and Clone icons appear on the bottom row.
While the Upsampler is streaming data via the
the bottom of the display, with the play/pause icon and the elapsed track time at the right hand side.
If the Upsampler is receiving a data stream in which the NonAudio flag has been set, the Upsampler
will mute and display for example: NA/44.1>DSD. The Vivaldi Transport (v1.10 or later) sets the
NonAudio flag when the CD tray opens and returns to Audio mode when playback starts.
Details of the menu displays are shown in the Menu section on page 39.
To avoid unnecessary display wear, we recommend switching off or setting the unit to
Sleep mode at the end of the listening session.
Vivaldi Upsampler Manual v2_0x
CD E F G H
Figure 8 – Front panel
Network
or
Page 33
Software Issue 2.0x
USB2
inputs, the track name appears at
November 2016
English version
