dCS Vivaldi Upsampler Plus User Manual
Customising the input configuration
The Vivaldi Upsampler's inputs can be renamed to suit your particular system using a computer
running a terminal emulator program. The Vivaldi DAC has the same feature. The procedure using a
Windows PC with TeraTerm is described here, but other programs such as PuTTY or ZTerm could be
used. If you have difficulty with this, please ask your Dealer for help.
• Power up the Upsampler and a Windows PC.
• If no suitable terminal program (for example Hyperterminal) is already installed, download Tera
Term from
http://en.sourceforge.jp/projects/ttssh2/releases/
broken, please search for the latest version of Tera Term online.)
Set the Upsampler's
• Use a USB-to-RS232 adapter cable to connect the
Test
Upsampler's
ports.
• Run ttermpro.exe.
• Click
Serial
the
automatically select the port connected to the
Upsampler. Click OK.
• Click Setup > Serial Port, set the Baud rate to 4800
and click OK.
• In the terminal window, type the command: NAME n = newname where:
-
n is the number corresponding to the standard input name in the list below:
AES
0
SPDIF3
3
USB1
6
newname is the personalised name you want to use for that input, such as CD, TV or
-
COMPUTER. It can be up to 8 characters long, consisting of:
• Press Enter.
For example:
-
to rename the
-
to rename the
Later on, if you want to revert to the standard input names (AES, SPDIF1, etc.), select the
Configuration > Reset Input Names
Your customised input names will be permanently deleted.
Vivaldi Upsampler Manual v2_0x
Settings > RS232
port to one of the PC's USB
button
–
Tera
Term
SPDIF1
Toslink
USB2
capital letters A-Z, numbers 0-9 or + - / = . : ? ! @ &
AES
input to CD, type: NAME 0 = CD and press enter.
Toslink
input to TV, type: NAME 4 = TV and press enter.
and install it on your PC. (If the link is
menu page to the Text option.
will
1
4
7
menu page.
Page 32
Software Issue 2.0x
November 2016
SPDIF2
2
SDIF-2
5
Network
9
English version
