dCS Vivaldi Upsampler Plus User Manual
DISPLAY SETTINGS Menu
Brightness
Set the display
Display On/Off
This page is usually set to On.
When set to
display will turn on briefly when a control setting is changed. The display will stay on if
the unit is not locked or is muted.
GENERATOR Menu
Channel Check
A routine to test the system for swapped channels. A tone is output on the left channel
only while the display shows Left, then the right channel only while the display shows
Right. If these are the wrong way around, the left and right channels are swapped
somewhere in your system. This test is not affected by the
setting.
Phase Check
A routine to test the system for phase reversals. Noise is output in phase on both
channels while the display shows
right channel is inverted while the display shows
produce a central image, the second burst should not. If these are the wrong way
around, one channel in your system is phase inverted. Press the
the test and return to the menu.
Burn In
A procedure to condition your system. The unit displays
outputs modulated pink noise that ramps up and down slowly in level. Press the
◄
►
or
buttons to stop the procedure.
!
Please ensure that the volume level is reasonable, as careless use of the
can damage your amplifiers and loudspeakers. dCS will not be liable for such damage.
Vivaldi Upsampler Manual v2_0x
Brightness
to a comfortable level using the
Off
and the menu closes, the display will turn off after a few seconds. The
In
Page 46
◄
Phase. Press the
Menu
Out of
Phase. The first burst should
Burn In Caution!
Software Issue 2.0x
November 2016
►
or
buttons.
Channel Swap
menu page
button, the noise on the
◄
►
or
button to stop
Loud, then
Menu
Burn In
feature
English version
or
