Overview

System Components

Modular hardware design makes the system easy to install and expand. The basic
system consists of a PARTNER ACS processor module, which supports three
lines and eight extensions. Using these lines and extensions, you can add various
optional devices and telephones to configure your system to meet your needs. To
expand the system to include more lines and extensions, simply attach additional
modules and a carrier to contain them. The term control unit is used to refer to the
stand-alone PARTNER ACS processor module (or to the carrier and the modules
it contains), since this is the heart of the system. Figure 1-1 shows an example of
system components.
!
WARNING:
There are no customer-serviceable components inside the system modules
or carrier. There are hazardous voltages within that can cause severe or fatal
personal injury. DO NOT OPEN THE MODULES.
1-4
