Address Point ID
+18-23 Reserved
+24 I maximum demand load current
+25 I4 maximum demand load current
+26-31 Reserved

Demands Setup

46240-46255
+0 Power demand period (block interval)
+1 Number of demand periods in a sliding window
+2 Demand synchronization source input
+3-7 Reserved
+8 Volt demand period
+9 Ampere demand period
+10 Harmonic demand period
+11-15 Reserved

Device Options Setup

46256-46271
+0 Power calculation mode
+1 Energy roll value
+2 Reserved
+3 End of billing (TOU/Billing maximum demand reset)
mode, bitmap
+4 Tariff control
+5 Number of tariffs
+6 PQ option
+7 Energy LED test mode
Description
0-20000
0-20000
1, 2, 3, 5, 10, 15, 30, 60
1-15
0 = device clock, 1-8 = DI1-DI8
0-9000
0-9000
0-9000
0 = using reactive power:
S = f(P,Q),
1 = using non-active power:
Q=f(S,P)
2 = 100,000.0 kWh
3 = 1,000,000.0 kWh
4 = 10,000,000.0 kWh
5 = 100,000,000.0 kWh (default)
Bit 0 = 1 – automatic/monthly
mode allowed
Bit 1 = 1 - COM mode allowed
Bit 2 = 1 - manual mode allowed
0 = via a calendar scheduler,
0x4000 = via communications,
0x0100-0x0107 = via tariff inputs
DI1-DI8 (bits 0:2 denote the first
digital input index used)
1-8 (does not have effect with a
calendar tariff control option)
2 = EN 50160:2007
5 = EN 50160:2010
0 = disabled, 1 = enabled
Options/Range Units
A
A
min
sec
sec
sec
Type R/W Notes
UINT16 R Read as 65535
UINT16 R/W
UINT16 R/W
UINT16 R Read as 65535
UINT16 R/W
UINT16 R/W
UINT16 R/W A DI input is considered a pulse or
KYZ input. The pulse edge restarts
the power demand accumulation
interval.
UINT16 R/W Read as 65535
UINT16 R/W
UINT16 R/W
UINT16 R/W
UINT16 R/W Read as 65535
UINT16 R/W
UINT16 R/W
UINT16 R/W Read as 65535
UINT16 R/W
UINT16 R/W
UINT16 R/W When read with a calendar tariff
control option, indicates the actual
number of tariffs selected in TOU
profiles
UINT16 R/W V26.XX.20 and later
UINT16 R/W
