Figure 1-11
The following items appear on the RMX 4000 rear panel:
Table 1-6
LAN 1- Modem
LAN 2-
Connection Management
Network
LAN 3 -
Signalling
network
RMX 4000 RTM-IP 4000 Rear Panel Layout
•
LAN 4, LAN 5 and the Serial ports are only for debugging and not for
customer use.
•
Do not remove the protective plastic caps from LAN 1, LAN 4 and LAN 5
ports.
RMX 4000 Rear Panel - RTM-IP 4000 Component Description
Item Description
LAN 1 Modem connection.
Note: LAN 1 is covered with a plastic cap that should not
be removed.
LAN 2 (CNTL Management network/Web Client connection.
4000/CPU 1)
LAN 3 (CNTL Signalling network, for Gatekeeper, Proxy or endpoint
4000/CPU 1) connections.
LAN 4-5 (CNTL Empty.
4000/CPU 2)
LAN 6 Shelf Manager connection.
Serial A 10/100 ShMG Shelf Manager connection.
For debugging purposes only.
USB USB key connection - TBD.
LAN 6- 10/100Mb ShMG (Shelf
Manager) & LEDs
LAN 4, 5 - Internal LAN
Empty
connection
LEDs
USB Standby button
Port & LED
Serial Port
