Altronix eBridge1STR Installation Manual page 3

Fig. 1 eBridge1PCRM
Structured
Cable from
midspan/endspan
Coax
Cable from
eBridge1ST
*Note: Caution: once PoE connection is established between eBridgePlus receiver and
eBridge1ST, disconnecting the eBridge1ST will not disable the PoE output voltage from the
eBridgePlus receiver. Although the eBridge1ST can be reconnected, caution should be taken
not to connect coax wiring from eBridgePlus receiver to any non-PoE device.
Fig. 2
eBridge1PCRM
eBridge1PCRM - Receiver
EoC/PoE+ Receiver
Supports PoE/PoE+
eBridge1PCRM
Optional Power Input: 24VDC/110mA or 24VAC/200mA
Optional Power Input: 24VDC/110mA or 24VAC/200mA
Blue LED Coax link status
Blue LED Coax link status
RJ45 LEDs Yellow - Speed, Green - Activity
RJ45 LEDs Yellow - Speed, Green - Activity
Green LED Power and PoE
Green LED Power and PoE
Z1409
Z1409
I.T.E. 43KC
www.altronix.com
www.altronix.com
100m max.
Powered Switch or NetWay MidSpan
Maximum Length of Coax Type vs. Camera Power/PoE Class:
Cable Type
RG59u/23awg
RG59u/23awg
RG59U/22awg
RG59U/22awg
RG59U/20awg
RG59U/20awg
RG59U/18awg
RG59U/18awg
eBridge1STR
Blue LED
indicates
Coax Connection
Single PoE Camera Connection:
Mounting Hole
--- +
--- +
Aux. 24VAC
or 24VDC Input
PoE/PoE+ over Coax up to 500m max.
Total Power
Consumption
13W
25W
13W
25W
13W
25W
13W
25W
eBridge1ST
Green LED
indicates
Power
Aux.
24VAC or
24VDC
Input
Yellow LED
indicates PoE
Mounting Hole
Max Data
Distance
500m
Structured
Cable from
Blue LED
Camera/Device
indicates
PoE Out
to Device
Fig. 2a
eBridge1ST
Coax Coax Coax
Link
Link
eBridge1ST - Transceiver
eBridge1ST - Transceiver
Supports PoE/PoE+ Supports PoE/PoE+
RJ45 LEDs Yellow - Speed RJ45 LEDs Yellow - Speed
Green - Activity Green - Activity
Green LED Power and PoE Green LED Power and PoE
www.altronix.com
Made in U.S.A. I.T.E. 43KC
www.altronix.com
PoE RJ45
RJ45
Out Link
Link
PoE compliant
100m max.
Legend:
Max Power
Distance
264m
132m
334m
167m
532m
266m
846m
423m
Flying BNC
Connector
PoE Camera
Structured Cable
Coax
- 3 -
