- Page 1 SY-CHQV Composite and Component to HDMI Scaler (HQV) OPERATION MANUAL...
-
Page 2: Safety Precautions
Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 3: Table Of Contents
Table of Contents 1. Introduction .................. 1 2. Applications ................. 1 3. Package Contents ..............1 4. System Requirements ..............1 5. Features ..................1 6. Specifications ................2 7. Operation Controls and Functions ..........3 Top Panel ..............3 Upper Panel .............. -
Page 4: Introduction
1. Introduction The SY-CHQV Scaler will format convert and scale Component and Compos- ite Video signals and outputs via HDMI. This scaler is specially designed for low resolution analog YCbCr video content to be upscaled to enable the signal to be displayed on a High Definition display. This scaler uses the HQV... -
Page 5: Specifications
6. Specifications Frequency bandwidth 2.25Mbps Input port 1 x CVBS, 1 x Component Output port 1 x HDMI Input Video Resolution 480i/p, 576i/p Output Resolution 480p, 720p, 1080p Power Supply 5V/1.2A USB jack (US/EU standards, CE/FCC/UL certified) ESD Protection Human body model: ±8kV (air-gap discharge) ±6kV(contact discharge) Dimensions (mm) 119.5(W) x 70(D) x 25(H) -
Page 6: Operation Controls And Functions
7. Operation Controls and Functions 7.1 Top Panel . Touch panel LED indicators: This is a touch panel controller, users can touch on the symbol or letters to switch in between the selection and the blue LEDs will illuminate according to user’s touch. Symbol represent power, press it once to turn ON the device and the LED will illuminate in blue, press it again to switch the device to... -
Page 7: Upper Panel
7.2 Upper Panel . CVBS & Audio IN: This slot is to connect with input source equipment such as consumer electronic camcorder device or video player for input signal sending. . COMP IN: This slot is to connect with input source equipment such as DVD player or iPod devices for input signal sending. -
Page 8: Remote Control
8. Remote Control 1. INPUT: Press this button to switch input source in between of CVBS or COMP. 2. Power: Press this button to turn ON or set the device to standby mode. 3. OUTPUT 480p/720p/1080p: Press these hot keys to select the desire output resolution of 480p/720p or 1080p. -
Page 9: Connection And Installation
9. Connection and Installation ipod Monitor Display... - Page 10 Acronyms Acronym Complete Term COMP Component CVBS Composite Video Broadcast Singal HDMI High-Definition Multimedia Interface Hollywood Quality Video MPEG Moving Picture Experts Group NTSC National Television System Committee Phase Alternating Line...
- Page 11 CIE-Group Ltd, Widdowson Close, Blenheim Industrial Estate, Bulwell, Nottingham NG6 8WB Tel: +44 (0)115 977 0075 | Fax: +44 (0)115 977 0081 Email: info@cie-group.com www.cie-group.com...
