Rabbit 3000 User Manual page 77

Table 6-2. Rabbit Internal I/O Registers (continued)
Register Name
Port E Bit 7 Register
Port F Data Register
Port F Control Register
Port F Function Register
Port F Drive Control Register
Port F Data Direction Register
Port G Data Register
Port G Control Register
Port G Function Register
Port G Drive Control Register
Port G Data Direction Register
Input Capture Ctrl/Status Register
Input Capture Control Register
Input Capture Trigger 1 Register
Input Capture Source 1 Register
Input Capture LSB 1 Register
Input Capture MSB 1 Register
Input Capture Trigger 2 Register
Input Capture Source 2 Register
Input Capture LSB 2 Register
Input Capture MSB 2 Register
I/O Bank 0 Control Register
I/O Bank 1 Control Register
I/O Bank 2 Control Register
I/O Bank 3 Control Register
I/O Bank 4 Control Register
I/O Bank 5 Control Register
I/O Bank 6 Control Register
I/O Bank 7 Control Register
PWM LSB 0 Register
User's Manual
Mnemonic I/O Address
PEB7R 0x7F
PFDR 0x38
PFCR 0x3C
PFFR 0x3D
PFDCR 0x3E
PFDDR 0x3F
PGDR 0x48
PGCR 0x4C
PGFR 0x4D
PGDCR 0x4E
PGDDR 0x4F
ICCSR 0x56
ICCR 0x57
ICT1R 0x58
ICS1R 0x59
ICL1R 0x5A
ICM1R 0x5B
ICT2R 0x5C
ICS2R 0x5D
ICL2R 0x5E
ICM2R 0x5F
IB0CR 0x80
IB1CR 0x81
IB2CR 0x82
IB3CR 0x83
IB4CR 0x84
IB5CR 0x85
IB6CR 0x86
IB7CR 0x87
PWL0R 0x88
R/W Reset
W xxxxxxxx
R/W xxxxxxxx
W xx00xx00
W xxxxxxxx
W xxxxxxxx
W 00000000
R/W xxxxxxxx
W xx00xx00
W xxxxxxxx
W xxxxxxxx
W 00000000
R/W 00000000
W xxxxxx00
W 00000000
W xxxxxxxx
R xxxxxxxx
R xxxxxxxx
W 00000000
W xxxxxxxx
R xxxxxxxx
R xxxxxxxx
W 000000xx
W 000000xx
W 000000xx
W 000000xx
W 000000xx
W 000000xx
W 000000xx
W 000000xx
W xxxxxxxx
69
