7.11 Pulse Width Modulator

The Pulse Width Modulator consists of a ten-bit free running counter, and four width reg-
isters. Each PWM output is High for "n+1" counts out of the 1024-clock count cycle,
where "n" is the value held in the width register. The PWM output High time can option-
ally be spread throughout the cycle to reduce ripple on the externally filtered PWM output.
The PWM is clocked by the output of Timer A9.
Register Name
PWM LSB 0 Register
PWM MSB 0 Register
PWM LSB 1 Register
PWM MSB 1 Register
PWM LSB 2 Register
PWM MSB 2 Register
PWM LSB 3 Register
PWM MSB 3 Register
The spreading function is implemented by dividing each 1024-clock cycle into four quad-
rants of 256 clocks each. Within each quadrant, the Pulse Width Modulator uses the eight
MSBs of each pulse-width register to select the base width in each of the quadrants. This
is the equivalent to dividing the contents of the pulse-width register by four and using this
value in each quadrant. To get the exact High time, the Pulse Width Modulator uses the
two LSBs of the pulse-width register to modify the High time in each quadrant according
to the table below. The "n/4" term is the base count, formed from the eight MSBs of the
pulse-width register.
Pulse Width LSBs
00
01
10
11
The diagram below shows a PWM output for several different width values, for both
modes of operation. Operation in the spread mode reduces the filtering requirements on
the PWM output in most cases.
User's Manual
Mnemonic I/O address
PWL0R 0x88
PWM0R 0x89
PWL1R 0x8A
PWM1R 0x8B
PWL2R 0x8C
PWM2R 0x8D
PWL3R 0x8E
PWM3R 0x8F
1st 2nd
n/4 + 1 n/4
n/4 + 1 n/4
n/4 + 1 n/4 + 1
n/4 + 1 n/4 + 1
R/W
W xxxxxxxx
W xxxxxxxx
W xxxxxxxx
W xxxxxxxx
W xxxxxxxx
W xxxxxxxx
W xxxxxxxx
W xxxxxxxx
3rd 4th
n/4 n/4
n/4 + 1 n/4
n/4 + 1 n/4
n/4 + 1 n/4 + 1
Reset
95
