Test current is the current to be used when running a test. Available
settings are 50, 100, 150, or 200A. You can also select Manual to use the
rotary knob on the instrument to control the current level during the test.
•
Language specifies the language to be used by the instrument's display.
•
Auto Save specifies whether or not a test is automatically saved at the time
it is performed.
•
Fan defines whether the fan is always on or runs in Auto mode (only turns
on when the instrument needs to cool its internal temperature).
•
Date format selects the format of dates to be used by the instrument
(European or USA).
•
Time format specifies whether the time is to be displayed using a 12 hour
(AM/PM) or a 24 hour clock.
On the right side of the Configuration Panel dialog box are five buttons:
•
Read from Instrument resets the options in this dialog box to reflect the
settings as they are set in the instrument.
•
Write to Instrument writes the configuration settings to the instrument.
•
Set Clock displays the Date/Time dialog box. This enables you to set the
instrument's time to a specific date and time, or synchronize the instrument's
clock with the PC's clock.
•
Delete Tests erases the instrument's memory. Note that after you confirm
that you want to proceed with the deletion; all objects are immediately
removed from memory, irrespective of whether you save any other changes
made through the Configuration Panel dialog box.
•
Cancel closes this dialog box discarding any changes specified without
writing them to the attached instrument.
Downloading Stored Tests
1.
To download stored tests, select Instrument from the menu bar, then click
Download. If a connection had not been previously established, the Connec-
tion dialog box will be displayed. Otherwise, the Select Tests dialog box will
appear displaying a list of tests stored in the instrument.
2.
Select the test you want to download by clicking it. You can select multiple
tests by holding down the Ctrl key while clicking your selections. Click Select
All to select all listed tests to download. After you have finished making selec-
tions, click the Download button.
3.
To edit the name and other properties of the test, double-click on the test's
name on the left side of the Control Panel.
4.
Click on the desired test to download (hold the Ctrl key to select multiple
tests), then click the Download button.
5.
To edit the name and other properties of the test, double-click on the Test's
name on the left side of the Control Panel.
NOTE: For complete operating instructions and more information on using
DataView, refer to the product user manual that is supplied on the USB stick.
