- Page 1 MR417 ■ AC/DC CURRENT PROBE MR527 ENGLISH User Manual GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
- Page 2 MR417 / MR527 Model #: Please fill in the appropriate date as indicated: Date Received: Date Calibration Due: Chauvin Arnoux ® , Inc. d.b.a AEMC ® Instruments Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
-
Page 3: Table Of Contents
CONTENTS 1 DESCRIPTION……..................7 1.1 Interface ........................8 1.1.1 MR417 ....................8 1.1.2 MR527 ....................9 2 OPERATION ....................10 2.1 Battery Installation ....................10 2.2 External Power (Optional)..................10 2.3 Turning ON the Instrument .................. 11 2.4 Auto Standby ......................11 2.5 DC Zero Adjustment .................... - Page 4 Thank you for purchasing the Current Probe Model MR417 or MR527. For best results from your instrument and for your safety, read the following operating instructions carefully and comply with the precautions for use. This instrument is compliant with the IEC 61010-2-032 safety standard for voltages of 300V with respect to earth in measurement category IV, or 600V in category III.
- Page 5 When handling the instrument, keep your fingers behind the physical guards. Use suitable means of protection. All troubleshooting and metrological checks must be performed by competent and accredited personnel. Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
- Page 6 Save the damaged packing container to substantiate your claim. Ordering Information AC/DC Current Probe Model MR417 ........... Cat. #1200.84 Includes 9V battery, multi-language safety data sheet and user manual AC/DC Current Probe Model MR527 ........... Cat. #1200.85...
-
Page 7: Description
1 DESCRIPTION The Models MR417 and MR527 are clamp-on current probes that measure DC currents up to 1400A, AC currents up to 1000A (1400A peak), and combined AC+DC currents without opening the circuit in which the currents flow. They indicate the shape and amplitude of the current measured in the form of a voltage. -
Page 8: Interface
OL (overload) and ON indicators. ON is green when Auto Standby is enabled, yellow when it disabled. 3-position slide switch USB port Trigger Hand guard Mobile jaw Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 9: Mr527
OL (overload) and ON indicators. ON is green when Auto Standby is enabled, yellow when it disabled. 3-position slide switch USB port Trigger Hand guard Mobile jaw Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 10: Operation
When operating on external power, the Auto Standby feature is disabled. The color of the ON indicator shows whether automatic standby is enabled (green) or disabled (yellow). Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 11: Turning On The Instrument
Then press DC Zero again. Alternately, turn the clamp OFF and then back ON. The previous zero adjustment will remain in effect. Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 12: Measurements
Figure 4 (MR527 shown) 2.6.2 Converting to Current The MR417 and MR527 both provide two measurement ranges. The MR417 measures current up to 600A with 1mV of output corresponding to 1A, and current up to 60A with 10mV corresponding to 1A. The MR527 measures current up to 1400A with 1mV corresponding to 1A, and current up to 150A with 10mV corresponding to 1A. -
Page 13: Specifications
3 to 300A 300 to 400A Phase shift ≤ -2.2° ≤ -1.5° MR527 Specified Measurement range 3 to 200A 200 to 1000A Phase shift ≤ -2° ≤ -1.5° Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... - Page 14 Typical amplitude error curve at 60Hz MR417 Error (%) Current (A) MR527 Error (%) Current (A) Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
- Page 15 Typical amplitude error curve in DC MR417 Error (%) Current (A) MR527 Error (%) Current (A) Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
- Page 16 Typical phase error curve at 60Hz MR417 Phase shift (°) Current (A) MR527 Phase shift (°) Current (A) Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
-
Page 17: Frequency Specifications, 1Mv/A Sensitivity
MR417: 2.8mΩ <0.01mΩ impedance MR527: 3.4mΩ MR527: 0.05mΩ MR527: 0.14mΩ Typical amplitude error versus frequency curve at 100A MR417 Error (%) Frequency (Hz) MR527 Error (%) Frequency (Hz) Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... - Page 18 Typical phase versus frequency error curve at 100A MR417 Phase shift (°) Frequency (Hz) MR527 Phase shift (°) Frequency (Hz) Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
-
Page 19: Electrical Specifications, 10Mv/A Sensitivity
MR417 Specified Measurement range 1 to 20A 20 to 40A Phase shift ≤ -3° ≤ -2.2° MR527 Specified Measurement range 1 to 100A Phase shift ≤ -2° Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... - Page 20 Typical amplitude error vs current curve at 60Hz MR417 Error (%) Current (A) MR527 Error (%) Current (A) Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
- Page 21 Typical amplitude error vs current curve in DC MR417 Error (%) Current (A) MR527 Error (%) Current (A) Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
- Page 22 Typical phase vs current error curve at 60Hz MR417 P hase shift (°) Current (A) MR527 Phase shift (°) Current (A) Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
-
Page 23: Frequency Specifications, 10Mv/A Sensitivity
Insertion <0.01mΩ impedance MR527: 0.05mΩ MR527: 0.14mΩ MR527: 3.4mΩ Typical amplitude error versus frequency curve at 100A MR417 Error (%) Frequency (Hz) MR527 Error (%) Frequency (Hz) Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... - Page 24 Typical phase versus frequency error curve at 100A MR417 Phase shift (°) Frequency (Hz) MR527 Phase shift (°) Frequency (Hz) Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
-
Page 25: Operating Limits
= 1000/f (kHz) Conductor temperature: ≤ 194°F (90°C), 230°F (110°C) peak Temperature of the jaws: ≤ 176°F (80°C) Curve of derating versus frequency Current (A) Frequency (kHz) Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 26: Variations In The Range Of Use
The average battery life is 50 hours with an alkaline battery. The instrument can also be powered by an external supply (5V , 100mA) via the type B micro‑USB connector. Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at:... -
Page 27: Environmental Conditions
1 = Range of reference 2 = Operating range 3 = Storage range Indoor use Degree of pollution: 2 Altitude: < 6500’ (2000m) Transport altitude: ≤ 40,000’ (12,000m) Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 28: Mechanical Specifications
(50 x 10mm) bar or two 1.24 x 0.30” (31.5 x 10mm), three 0.98 x 0.31” (25 x 8mm) bars, two 0.98 x 0.2” (25 x 5mm) bars Figure 5 Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at:... - Page 29 1.96 x 0.2” (50 x 5mm) bars or 1.24 x 0.30” (31.5 x 10mm), three 0.98 x 0.31” (25 x 8mm) bars, two 0.98 x 0.2” (25 x 5mm) bars Figure 6 Current Probe Models MR417/MR527 GlobalTestSupply www.
-
Page 30: Housing Protection
The instrument is compliant with IEC 61010-2-032, 300V in CAT IV or 600V in CAT III. Double or reinforced insulation Type of current sensor per IEC 61010-2-032: type A 3.9 Electromagnetic Compatibility The device is in conformity with standard IEC 61326-1. Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 31: Maintenance
5. Replace the battery compartment cover. Spent batteries must not be treated as ordinary household waste. Take them to the appropriate collection point for recycling. Current Probe Models MR417/MR527 GlobalTestSupply www. .com Find Quality Products Online at:...
